2 Reference🔗ℹ

Every binding below is provided by glmnet, except those of Nested lists and vectors, CSV files, Matrices from math/matrix, Polars dataframes, Example datasets and Plots, whose sections name the modules that provide them. Each model family has a fit procedure, a path fitter, a cross-validation procedure, a transparent result struct and prediction helpers. The formula front end (Formulas) fits any family from a table. Every result type, glmnet-path, glmnet-cv and formula-model also implement the generic interface of Generic model interface: predict, coef and deviance-ratio work on all of them, and they print as summaries. Concepts explains how the pieces fit together.

2.1 Common arguments🔗ℹ

The fit procedures share their argument conventions:

X is a design matrix, one row per observation: a design-matrix? value, a non-empty list or vector of equal-length rows of reals, each row a list or a vector (see design-matrix/c, Input data and Nested lists and vectors), or a math/matrix matrix. Prediction helpers take new data in the same forms, with as many columns as the fit has coefficients.
A response y, and an unnamed Cox fit’s statuses, is a non-empty list, vector, flvector or f64vector with one entry per row of X (see response/c), a math/array array or a Polars series; a Cox status may also be a boolean, #t for an event.
Every procedure also takes named data, a table or a Polars dataframe, whose response and predictors it selects by name (see Data arguments).
#:lambda is the penalty strength λ ≥ 0. It is required.
#:alpha is the mixing parameter α ∈ [0, 1]: 0.0 is the ridge penalty, 1.0 (the default) the lasso, and values in between the elastic net.
#:standardize? scales each predictor to unit variance before fitting; coefficients are always reported on the original scale.
#:intercept? fits an unpenalized intercept; #f fixes it at zero.
#:thresh is the coordinate-descent convergence threshold and #:max-iters the maximum number of passes.

Before the solver runs, an argument of the wrong type, a ragged or empty matrix, a non-finite entry, or a response of the wrong length raises exn:fail:contract; the message names the offending row and column or position. A fatal condition reported by glmnet raises exn:fail with a readable message. So does a fit for which glmnet fits no λ at all, for example because it does not converge within #:max-iters passes; the message names the procedure called and gives glmnet’s reason. (R warns instead, and returns an empty model.)

2.1.1 Data arguments🔗ℹ

The fit, path and cross-validation procedures take their data as it is, and give the results of the explicit conversions of Input data, Matrices from math/matrix and Polars dataframes. Unnamed data is as above. Named data, a table that is not a design matrix or a Polars dataframe, is read by column name: y names the response, and #:predictors, then required, lists the predictor columns in the order of the coefficients. Nothing is guessed: a column is used only when it is named, no row is dropped, and a missing value, a value that is not a real number or one that is not finite is an error naming its column and row. A design matrix is unnamed data, even when its columns have names. An association list whose columns are lists, such as '(("x" 1 2) ("y" 3 4)), is also a list of rows: it is named data when y names columns, and rows otherwise. A list of strings or symbols given to a binomial or multinomial fitter is class labels, never column names.

The response is one column, except for two families:

Family	y for named data	Unnamed data
Gaussian, Poisson	a numeric column	a response
Binomial, multinomial	a column of class labels	a response of class labels
Cox	'("time" "status"), two columns	the times, and the statuses after them
Multi-response	'("y1" "y2"), a non-empty list	a matrix, one column per response

A binomial or multinomial response, a column, a list, a vector, a Polars series or a math/array array, may hold strings, symbols or booleans in place of class numbers. Its classes are then its levels, as a formula’s factor response has them: strings and symbols sorted by string<?, which is R’s order in the C locale (R in another locale sorts mixed-case labels differently), and "FALSE" before "TRUE". A binomial response has exactly two. The fit remembers them, and predict with #:type 'class, logistic-predict and multinomial-predict return them.

A fit from named data remembers its predictors’ names: predict and the prediction helpers read new named data, and a design matrix with column names, by them, in any order, ignoring other columns, the response included, and other unnamed data by position. A fit from unnamed data reads only unnamed data. The result is the same struct as from the explicit conversions, and equal? to it, though a copy made by struct-copy does not remember the names; coef keeps its layout, and plot-coefficient-path labels the curves by name and a multi-response fit’s panels by its responses’ names.

(require glmnet) loads neither Polars nor math/matrix; their values are recognised once the program has loaded the library itself.

Examples:

> (define autos
    (dataframe (list (series '(21.0 22.8 21.4 18.7 18.1 14.3) #:name "mpg")
                     (series '(2.62 2.32 3.215 3.44 3.46 3.57) #:name "wt")
                     (series '(110 93 110 175 105 245) #:name "hp"))))
> (define car-fit (ols autos "mpg" #:predictors '("wt" "hp")))
> (coef car-fit)
'#(31.51526192771049 -2.5190175381213304 -0.030876933077271105)
> (predict car-fit (hash "hp" '(150) "wt" '(3.0) "model" '("new")))
'(19.326669351755836)
> (predict car-fit '((3.0 150)))
'(19.326669351755836)
> (equal? (ols (matrix [[2.62 110] [2.32 93] [3.215 110] [3.44 175] [3.46 105] [3.57 245]])
               (array #[21.0 22.8 21.4 18.7 18.1 14.3]))
          (ols '((2.62 110) (2.32 93) (3.215 110) (3.44 175) (3.46 105) (3.57 245))
               '(21.0 22.8 21.4 18.7 18.1 14.3)))
#t
> (define flowers (multinomial-fit iris "Species" #:lambda 0.05
                                   #:predictors '("Petal.Length" "Petal.Width")))
> (multinomial-predict flowers (hash "Petal.Length" '(1.4 4.5 6.0) "Petal.Width" '(0.2 1.5 2.5)))
'("setosa" "versicolor" "virginica")
> (ols autos "mpg")
ols: contract violation
  #:predictors is required when X is a dataframe; it names
the predictor columns, as in #:predictors '("wt" "hp")
  in: (->*
       (data/c (response-for/c X real?))
       (#:predictors (predictors-for/c X y) ...)
       elnet-result?)
  contract from: <pkgs>/glmnet/core/elnet.rkt
  blaming: program
   (assuming the contract is correct)
  at: <pkgs>/glmnet/core/elnet.rkt:37:3
> (ols autos "mpg" #:predictors '("wt" "mpg"))
ols: contract violation
  expected: a non-empty list of distinct names of numeric
columns of the dataframe, without the response
  given: column "mpg", which is the response
  in: the #:predictors argument of
      (->*
       (data/c (response-for/c X real?))
       (#:predictors (predictors-for/c X y) ...)
       elnet-result?)
  contract from: <pkgs>/glmnet/core/elnet.rkt
  blaming: program
   (assuming the contract is correct)
  at: <pkgs>/glmnet/core/elnet.rkt:37:3

value
data/c : flat-contract?

The contract on the X argument of the fit, path and cross-validation procedures and the new data of predict and the prediction helpers: unnamed data, a design matrix, rows in any of the nestings of design-matrix/c or a math/matrix matrix, or named data, a table or a Polars dataframe.

Examples:

> (contract-first-order-passes? data/c '((1.0 2.0) (3.0 4.0)))
#t
> (contract-first-order-passes? data/c autos)
#t
> (contract-first-order-passes? data/c (hash "x" '(1 2)))
#t
> (contract-first-order-passes? data/c '(1.0 2.0))
#f

procedure
(named-data? v) → boolean?
v : any/c

Returns #t if v is named data: a table that is not a design matrix, or a Polars dataframe.

Examples:

> (named-data? autos)
#t
> (named-data? (list (cons "x" '(1 2))))
#t
> (named-data? (rows->design-matrix '((1 2)) #:column-names '(a b)))
#f

procedure
(response-for/c X elem [#:classes? classes?]) → flat-contract?
  X : data/c
  elem : flat-contract?
  classes? : boolean? = #f

The contract on the y argument, given X. For named data, y is the name of one of its columns, a string or a symbol, with a numeric dtype when X is a dataframe. Otherwise, y is (response/c elem), or a math/array array, as array->response takes, or a Polars series, whose entries are checked as they are read. With classes?, for the binomial and multinomial families, the column, or the list or vector, may also hold strings and symbols, or booleans: class labels. The Gaussian procedures use (response-for/c X real?).

Examples:

> (contract-first-order-passes? (response-for/c autos real?) "mpg")
#t
> (contract-first-order-passes? (response-for/c autos real?) "weight")
#f
> (contract-first-order-passes? (response-for/c '((1.0) (2.0)) real?) '(3 4))
#t
> (contract-first-order-passes? (response-for/c '((1.0) (2.0)) (or/c 0 1) #:classes? #t)
'(yes no))
#t

procedure
(survival-for/c X) → flat-contract?
X : data/c

The contract on a Cox fit’s y, given X. For named data, a list of the names of two of its columns, the time, numeric, and then the status, numeric or boolean; otherwise the times, (response-for/c X (>/c 0)).

Examples:

> (define survival (list (cons "x" '(1 2 3)) (cons "t" '(5.0 3.0 6.0)) (cons "d" '(1 0 1))))
> (contract-first-order-passes? (survival-for/c survival) '("t" "d"))
#t
> (contract-first-order-passes? (survival-for/c survival) "t")
#f

procedure
(statuses-for/c X y) → flat-contract?
X : data/c
y : any/c

The contract on an unnamed Cox fit’s statuses, given X and y: (response-for/c X (or/c 0 1)), or booleans, #t for an event, as R’s Surv reads a logical status. Named data takes no statuses argument, since y names the status column.

Examples:

> (contract-first-order-passes? (statuses-for/c '((1.0) (2.0)) '(5.0 3.0)) '(1 0))
#t
> (contract-first-order-passes? (statuses-for/c '((1.0) (2.0)) '(5.0 3.0)) '(#t #f))
#t
> (contract-first-order-passes? (statuses-for/c survival '("t" "d")) '(1 0 1))
#f

procedure
(responses-for/c X) → flat-contract?
X : data/c

The contract on a multi-response fit’s Y, given X. For named data, a non-empty list of distinct names of its numeric columns; otherwise unnamed data with one column per response.

Examples:

> (contract-first-order-passes? (responses-for/c autos) '("mpg" "hp"))
#t
> (contract-first-order-passes? (responses-for/c '((1.0) (2.0))) '((3.0 4.0) (5.0 6.0)))
#t

procedure
(predictors-for/c X y [#:classes? classes?]) → flat-contract?
  X : data/c
  y : any/c
  classes? : boolean? = #f

The contract on the #:predictors argument, given X and y. For named data, a non-empty list of distinct names of its columns, numeric ones for a dataframe, without the response y, or any of its names when it is a list; it is required. For unnamed data, a design matrix with column names included, only #f, since every column of X is a predictor. With classes?, as for the binomial and multinomial families, a list y is class labels: on an association list whose columns are lists, X is then rows, and only #f is accepted.

Examples:

> (define car-predictors/c (predictors-for/c autos "mpg"))
> (contract-first-order-passes? car-predictors/c '("wt" hp))
#t
> (contract-first-order-passes? car-predictors/c '("wt" "mpg"))
#f
> (contract-first-order-passes? car-predictors/c '("wt" "wt"))
#f
> (contract-first-order-passes? (predictors-for/c '(("x" 1 2) ("d" 1 0)) '("d") #:classes? #t)
'("x"))
#f

2.2 Input data🔗ℹ

(require glmnet/data)

package: glmnet

A design-matrix? value holds a design matrix in the layout the Fortran reads: an array of doubles stored column by column, so that element (i, j) of a matrix with n rows is at index i + jn, with indices counted from 0. It also records the numbers of rows and columns, and optional column names. See Data.

Every conversion into a design matrix copies its input and checks it: the matrix needs at least one row and one column, every row (or column) the same length, and every entry must be a real, finite number. Exact numbers become flonums. A violation raises exn:fail:contract, with a message that names the offending row and column. Because nothing can modify a design matrix after it is built, it passes these checks for its whole life, and one design matrix can be passed to any number of fits.

glmnet re-exports every binding in this section. glmnet/data provides them without loading the native library.

procedure
(design-matrix? v) → boolean?
v : any/c

Returns #t if v is a design matrix, and #f otherwise. Two design matrices are equal? when they have the same dimensions, entries and column names. A design matrix prints with its dimensions only.

Examples:

> (define D (rows->design-matrix '((1.0 4.0) (2.0 5.0) (3.0 6.0))))
> (design-matrix? D)
#t
> D
#<design-matrix 3x2>
> (equal? D (columns->design-matrix '((1 2 3) (4 5 6))))
#t

value
design-matrix/c : flat-contract?

The contract on the X argument of every fit and prediction procedure, and on the response matrix Y of mgaussian-fit, mgaussian-path and mgaussian-cv. It accepts a design-matrix? value, or rows in any of four nestings: a list or a vector of rows, each row a list or a vector. Each of those procedures converts and checks the rows as nested->design-matrix does, so every nesting fits exactly as the same list of lists. A violation reports the contract’s name, (or/c design-matrix? (listof (or/c list? vector?)) (vectorof (or/c list? vector?))); unlike vectorof, the contract never wraps a vector.

Examples:

> (contract-first-order-passes? design-matrix/c D)
#t
> (contract-first-order-passes? design-matrix/c '((1.0 2.0) (3.0 4.0)))
#t
> (contract-first-order-passes? design-matrix/c (vector #(1.0 2.0) '(3.0 4.0)))
#t
> (contract-first-order-passes? design-matrix/c '(1.0 2.0))
#f

procedure
(response/c elem) → flat-contract?
elem : flat-contract?

A contract for a one-dimensional input, such as a response: a non-empty list, vector, flvector or f64vector each of whose elements is a real number that satisfies elem. The elements are checked with real? first because a number contract such as (or/c 0 1) compares with =, which the complex number 1.0+0.0i passes. The fit procedures use it for their responses, for example (response/c (or/c 0 1)) for the labels of logistic-fit, and check elem again on the flonums they convert the response to, so that a positive time too small for a flonum, which becomes 0.0, is an error. A violation names the accepted shapes, or the position of the first element that fails elem, counting from 0. Like design-matrix/c, it never wraps a vector. Two response/c contracts are contract-equivalent? when their element contracts are, and one is contract-stronger? than another when its element contract is.

Examples:

> (require racket/flonum)
> (define labels/c (response/c (or/c 0 1)))
> (contract-first-order-passes? labels/c '(0 1 1))
#t
> (contract-first-order-passes? labels/c (flvector 0.0 1.0))
#t
> (contract-first-order-passes? labels/c (vector 0 2))
#f
> (contract-first-order-passes? labels/c (vector))
#f
> (define/contract (events statuses)
    (-> (response/c (or/c 0 1)) exact-nonnegative-integer?)
    (for/sum ([s statuses]) (if (= s 1) 1 0)))
> (events (vector 1 0 1))
2
> (events (flvector 1.0 0.0 0.5))
events: contract violation
  expected: (or/c 0 1)
  given: 0.5
  in: the element at position 2 of
      the 1st argument of
      (-> (response/c (or/c 0 1)) natural?)
  contract from: (function events)
  blaming: program
   (assuming the contract is correct)
  at: eval:50:0
> (contract-equivalent? (response/c (>/c 0)) (response/c (>/c 0)))
#t

procedure
(rows->design-matrix rows
[ #:column-names column-names])
→ design-matrix?
rows : (listof list?)
column-names : (or/c #f (listof (or/c string? symbol?))) = #f

Builds a design matrix from a list of rows, one per observation. Every row must have the same length, and every entry must be a real, finite number. column-names, when given, names the columns: one distinct string or symbol per column. Names are compared as strings, so "x" and 'x are the same name, and the design matrix keeps each as a string, so that the same data named with symbols or with strings gives equal? design matrices, whatever it was converted from. For rows that are vectors, or a vector of rows, see nested->design-matrix.

Examples:

> (define named (rows->design-matrix '((1 2) (3 4)) #:column-names '(age dose)))
> (design-matrix->rows named)
'((1.0 2.0) (3.0 4.0))
> (design-matrix-column-names named)
'("age" "dose")
> (rows->design-matrix '((1.0 2.0) (3.0 4.0) (5.0)))
rows->design-matrix: the matrix has rows of different
lengths
  row: 2
  length: 1
  length of row 0: 2
> (rows->design-matrix '((1.0 2.0) (3.0 +inf.0)))
rows->design-matrix: the matrix has an element that is not
finite
  column: 1
  row: 1
  element: +inf.0
> (rows->design-matrix '((1.0 2.0)) #:column-names '(a))
rows->design-matrix: the number of column names does not
match the columns
  column names: 1
  columns: 2
> (rows->design-matrix '((1.0 2.0)) #:column-names '("x" x))
rows->design-matrix: the column names are not distinct
  duplicate: 'x
  column names: '("x" x)

procedure
(columns->design-matrix columns
[ #:column-names column-names])
→ design-matrix?
columns : (listof list?)
column-names : (or/c #f (listof (or/c string? symbol?))) = #f

Builds a design matrix from a list of columns, one per predictor, under the same rules as rows->design-matrix. For columns in the other nestings, see nested->design-matrix with #:by 'columns.

Examples:

> (design-matrix->rows (columns->design-matrix '((1 2 3) (4 5 6))))
'((1.0 4.0) (2.0 5.0) (3.0 6.0))
> (columns->design-matrix '((1.0 2.0 3.0) (4.0 +nan.0 6.0)))
columns->design-matrix: the matrix has an element that is
not finite
  column: 1
  row: 1
  element: +nan.0

procedure
(f64vector->design-matrix v
nrows
ncols
[ #:column-names column-names])
→ design-matrix?
  v : f64vector?
  nrows : exact-positive-integer?
  ncols : exact-positive-integer?
  column-names : (or/c #f (listof (or/c string? symbol?))) = #f

Builds a design matrix from v, an array already in the column-major layout: element (i, j) is at index i + j · nrows. The contract requires the length of v to be (* nrows ncols), and every entry must be finite. The design matrix holds a copy, so later changes to v do not affect it.

Examples:

> (require ffi/vector)
> (define v (f64vector 1.0 2.0 3.0 4.0 5.0 6.0))
> (design-matrix->rows (f64vector->design-matrix v 3 2))
'((1.0 4.0) (2.0 5.0) (3.0 6.0))
> (design-matrix->rows (f64vector->design-matrix v 2 3))
'((1.0 3.0 5.0) (2.0 4.0 6.0))
> (f64vector->design-matrix v 4 2)
f64vector->design-matrix: contract violation
  expected: an f64vector of length nrows * ncols = 8
  given: an f64vector of length 6
  in: the v argument of
      (->i
       ((v
         (nrows ncols)
         (f64vector-length/c nrows ncols))
        (nrows exact-positive-integer?)
        (ncols exact-positive-integer?))
       (#:column-names
        (column-names
         (or/c
          #f
          (listof (or/c string? symbol?)))))
       (result design-matrix?))
  contract from: <pkgs>/glmnet/data.rkt
  blaming: program
   (assuming the contract is correct)
  at: <pkgs>/glmnet/data.rkt:34:3

procedure
(design-matrix-nrows dm) → exact-positive-integer?
dm : design-matrix?
procedure
(design-matrix-ncols dm) → exact-positive-integer?
dm : design-matrix?

The number of rows (observations) and columns (predictors) of dm.

Examples:

> (design-matrix-nrows D)
3
> (design-matrix-ncols D)
2

procedure
(design-matrix-column-names dm) → (or/c #f (listof string?))
dm : design-matrix?

The column names dm was built with, as strings, or #f if it has none. A design matrix with column names is a table, from which the formula front end fits by name; the fits from a matrix do not use the names.

Examples:

> (design-matrix-column-names D)
#f
> (define cols '((1 2) (3 4)))
> (design-matrix-column-names
(columns->design-matrix cols #:column-names '("x1" x2)))
'("x1" "x2")

procedure
(design-matrix-ref dm i j) → flonum?
  dm : design-matrix?
  i : exact-nonnegative-integer?
  j : exact-nonnegative-integer?

The entry in row i and column j of dm, counting from 0. The contract requires i to be less than (design-matrix-nrows dm) and j less than (design-matrix-ncols dm).

Examples:

> (design-matrix-ref D 2 1)
6.0
> (design-matrix-ref D 3 0)
design-matrix-ref: contract violation
  expected: (integer-in 0 2)
  given: 3
  in: the i argument of
      (->i
       ((dm design-matrix?)
        (i
         (dm)
         (integer-in
          0
          (sub1 (design-matrix-nrows dm))))
        (j
         (dm)
         (integer-in
          0
          (sub1 (design-matrix-ncols dm)))))
       (result flonum?))
  contract from: <pkgs>/glmnet/data.rkt
  blaming: program
   (assuming the contract is correct)
  at: <pkgs>/glmnet/data.rkt:43:3

procedure
(design-matrix-select-rows dm rows) → design-matrix?
dm : design-matrix?
rows : (and/c (listof exact-nonnegative-integer?) pair?)

A new design matrix of the rows of dm at the indices rows, counting from 0, in the order given and with the same column names. An index can appear more than once. The rows are copied without being checked again. Cross-validation uses it to split one design matrix into folds.

Examples:

> (design-matrix->rows (design-matrix-select-rows D '(2 0)))
'((3.0 6.0) (1.0 4.0))
> (design-matrix->rows (design-matrix-select-rows D '(1 1)))
'((2.0 5.0) (2.0 5.0))
> (design-matrix-select-rows D '(0 3))
design-matrix-select-rows: row index is out of range
  row index: 3
  valid range: [0, 2]
  design matrix: #<design-matrix 3x2>

procedure
(design-matrix->rows dm) → (listof (listof flonum?))
dm : design-matrix?
procedure
(design-matrix->columns dm) → (listof (listof flonum?))
dm : design-matrix?

The entries of dm as a list of rows or as a list of columns.

Examples:

> (design-matrix->rows D)
'((1.0 4.0) (2.0 5.0) (3.0 6.0))
> (design-matrix->columns D)
'((1.0 2.0 3.0) (4.0 5.0 6.0))

procedure
(design-matrix->f64vector dm) → f64vector?
dm : design-matrix?

A fresh copy of the column-major array that dm holds.

Example:

> (f64vector->list (design-matrix->f64vector D))
'(1.0 2.0 3.0 4.0 5.0 6.0)

procedure
(response->f64vector y) → f64vector?
y : (or/c list? vector? flvector? f64vector?)

Converts a non-empty list, vector, flvector or f64vector of real, finite numbers to a fresh f64vector, the form in which a response reaches the Fortran. The fit procedures apply the same conversion to their responses, after checking that the response has one entry per row of X. An flvector is always copied, since the FFI cannot pass one where the Fortran expects an f64vector; so is an f64vector, so that the result never shares memory with y. An error names the position of the offending entry, counting from 0.

Examples:

> (f64vector->list (response->f64vector '(1 1/2 2.5)))
'(1.0 0.5 2.5)
> (f64vector->list (response->f64vector (vector 1 1/2 2.5)))
'(1.0 0.5 2.5)
> (f64vector->list (response->f64vector (flvector 1.0 0.5 2.5)))
'(1.0 0.5 2.5)
> (response->f64vector (flvector 1.0 +nan.0 2.0))
response->f64vector: the response has an element that is not
finite
position: 1
element: +nan.0

2.2.1 Tables🔗ℹ

A table holds named columns, and is what the formula front end (Formulas) fits from. A column name is a string or a symbol, and names are compared as strings; a column is a list, vector, flvector or f64vector of reals, or a list or vector of strings, symbols or booleans, which the formula front end reads as a factor. A table is one of:

a non-empty association list of (name . column) pairs, whose columns are in the list’s order;
a non-empty hash from name to column, whose columns are in the order of their names, sorted with string<?;
a design-matrix? with column names, in the order of its columns.

Only the columns that are selected are checked: every entry of a column selected as numbers must be a real, finite number, and the selected columns must have the same length, at least 1. An error names the column, and the row of an entry that is wrong. The guide’s Formulas and named data chapter shows tables in use.

procedure
(table? v) → boolean?
v : any/c

Returns #t if v is a table: an association list or hash whose names are strings or symbols and whose columns are lists, vectors, flvectors or f64vectors, or a design matrix with column names. The entries of the columns are not checked.

Examples:

> (define patients
    (list (cons "age" '(34 51 67))
          (cons 'dose #(2.0 5.5 1.0))
          (cons "id" '("a" "b" "c"))))
> (table? patients)
#t
> (table? (hash "x" '(1 2)))
#t
> (table? named)
#t
> (table? D)
#f
> (table? '((1 2) (3 4)))
#f

procedure
(table-column-names table) → (listof string?)
table : table?

The names of table’s columns, as strings, in the table’s order. Two columns whose names are the same string are an error.

Examples:

> (table-column-names patients)
'("age" "dose" "id")
> (table-column-names (hash 'b '(1) "a" '(2)))
'("a" "b")
> (table-column-names (hash "a" '(1) 'a '(2)))
table-column-names: the table has two columns with the same
name
name: "a"

procedure
(table->design-matrix table [names]) → design-matrix?
table : table?
names : (and/c (listof (or/c string? symbol?)) pair?)
= (table-column-names table)

A design matrix of the columns of table named by names, in that order, with those names, as strings, as its column names. Each name must be a column of the table, and must appear once.

Examples:

> (define P (table->design-matrix patients '(dose "age")))
> (design-matrix->rows P)
'((2.0 34.0) (5.5 51.0) (1.0 67.0))
> (design-matrix-column-names P)
'("dose" "age")
> (table->design-matrix patients)
table->design-matrix: the table has an element that is not a
real number
  column: "id"
  row: 0
  element: "a"
> (table->design-matrix patients '("age" "weight"))
table->design-matrix: the table has no column with this name
  column: "weight"
  columns of the table: '("age" "dose" "id")

2.3 Nested lists and vectors🔗ℹ

(require glmnet/data/nested)

package: glmnet

Racket’s own data for a design matrix is a list or a vector of rows, each row a list or a vector. Every fit and prediction procedure accepts these four nestings as they are (see design-matrix/c). This module converts them to a design-matrix? value, to check the data once and fit it many times or to name its columns, and converts a design matrix back to any of them. A response needs no conversion of its own: a list, vector, flvector or f64vector is accepted wherever a response is (see response/c and response->f64vector). glmnet does not re-export this module.

rows->design-matrix and columns->design-matrix are the list-of-lists cases of nested->design-matrix. The three read their input the same way, so the same entries give equal? design matrices, and so do the fits and predictions on them.

procedure
(nested->design-matrix xss
[ #:by by
#:column-names column-names])
→ design-matrix?
   xss :
(or/c (listof (or/c list? vector?))
      (vectorof (or/c list? vector?)))
  by : (or/c 'rows 'columns) = 'rows
  column-names : (or/c #f (listof (or/c string? symbol?))) = #f

Builds a design matrix from xss, whose elements are the rows of the matrix when by is 'rows and its columns when by is 'columns. xss is one list or one vector, and its rows (or columns) can be any mix of lists and vectors. The rules are those of rows->design-matrix: at least one row and one column, every row (or column) of the same length, every entry a real, finite number, and column-names, when given, one distinct name per column. A design matrix with column names is a table, from which the formula front end fits by name.

Examples:

> (require glmnet/data/nested)
> (define vrows (vector #(1.0 4.0) #(2.0 5.0) #(3.0 6.0)))
> (define V (nested->design-matrix vrows))
> (design-matrix->rows V)
'((1.0 4.0) (2.0 5.0) (3.0 6.0))
> (equal? V (nested->design-matrix (list #(1 2 3) '(4 5 6)) #:by 'columns))
#t
> (equal? V (rows->design-matrix '((1 4) (2 5) (3 6))))
#t
> (design-matrix-column-names (nested->design-matrix vrows #:column-names '(x z)))
'("x" "z")
> (nested->design-matrix (vector #(1.0 2.0) #(3.0)))
nested->design-matrix: the matrix has rows of different
lengths
  row: 1
  length: 1
  length of row 0: 2

procedure
(design-matrix->nested dm
[ #:by by
#:outer outer
#:inner inner]) → (or/c list? vector?)
  dm : design-matrix?
  by : (or/c 'rows 'columns) = 'rows
  outer : (or/c 'list 'vector) = 'list
  inner : (or/c 'list 'vector) = 'list

The entries of dm, as flonums: its rows when by is 'rows, and its columns when it is 'columns. They are held in an outer (a list or a vector) of inners, so that the defaults give the list of lists of design-matrix->rows. The vectors are fresh and mutable. The column names are not included; see design-matrix-column-names.

Examples:

> (design-matrix->nested V #:outer 'vector #:inner 'vector)
'#(#(1.0 4.0) #(2.0 5.0) #(3.0 6.0))
> (design-matrix->nested V #:inner 'vector)
'(#(1.0 4.0) #(2.0 5.0) #(3.0 6.0))
> (design-matrix->nested V #:by 'columns #:outer 'vector)
'#((1.0 2.0 3.0) (4.0 5.0 6.0))
> (equal? (design-matrix->nested V) (design-matrix->rows V))
#t

2.4 CSV files🔗ℹ

(require glmnet/data/csv)

package: glmnet

glmnet/data/csv reads and writes tables as CSV files, following RFC 4180. glmnet does not re-export it. See CSV files.

When reading, the input must be UTF-8. The first record is the header, whose cells name the columns: each name must be non-empty and appear once. Records end with a line feed, a carriage return or both, and the last one need not; a byte-order mark at the start is skipped. A cell in double quotes can hold commas, line breaks and double quotes, which are written twice. Every record must have one cell per column.

Each cell is typed on its own, as R’s read.csv types a column that holds only that cell:

A cell is missing when it is NA, quoted or not, or when it is not quoted and is empty or holds only white space. A missing cell is an error.
A number is a flonum. A number is a decimal number, such as 3, -2.5, .5, 5. or 1e-3; a hexadecimal one, such as 0x1A, 0x.8 or 0x1.8p1; or Inf, Infinity or NaN, in any case; each with an optional sign. White space around a number is ignored. A number is rounded correctly, however many digits it has, which R’s reader does not always do for a decimal number. -0 is -0.0, where R reads it as the integer 0.
TRUE and T are #t, and FALSE and F are #f. Other spellings, such as true or False, are strings, as they are in R.
Any other cell is a string, as it is written between the quotes, white space included: " TRUE" and "NA " are strings, as they are in R, and "" is the empty string.

White space is what R takes as white space in a UTF-8 locale: space, tab, line feed, vertical tab, form feed and carriage return, and the Unicode spaces U+1680, U+2000 to U+2006, U+2008 to U+200A, U+2028, U+2029, U+205F and U+3000, but not the no-break spaces U+00A0, U+2007 and U+202F. It makes a cell blank, and it can follow a number; before a number, only the ASCII white space is skipped, as in R. In the C locale R takes only the ASCII white space, and reads a cell of Unicode spaces as a string.

Quotes change the value of a cell only when it is empty or holds only white space: then it is a string when it is quoted, and missing when it is not, where R reads both as missing. A number, a logical or NA is the same with or without quotes, as in R. Unlike R, which gives a whole column one type, a column can mix kinds: a column of the letters A, C, G and T, which R reads as strings, holds three strings and #t, and a formula that reads it raises an error naming the column. R’s complex numbers, such as 1i, are strings.

The table is an association list from each name, a string, to its column, a vector, in the header’s order. An error names the procedure called, the column, the row, counting from 0, and the line of the input on which the row starts, counting from 1, and the file when there is one. Input that is not UTF-8 is an error that names the line and the offset of its first byte that is not, counting from 0.

When writing, the header is the table’s column names, in its order, and then there is one line per row, each ended by a line feed; a table whose columns are empty is its header alone. A real is written as the shortest decimal that reads back as the same flonum, without a trailing .0; an infinity as Inf or -Inf, as R writes it; and a NaN as NaN, which R reads back as NaN, where R’s write.csv writes NA. A boolean is TRUE or FALSE, and a string, or a symbol’s name, is written as it is. A cell or a name is quoted when it holds a comma, a double quote or a line break, starts or ends with white space or starts with a byte-order mark, or is empty, and a string is also quoted when it would read as another value, such as "42" or "T", as R’s write.csv quotes every string. It still reads back as that value, as it does in R. A string that would read back as a missing value, "NA", cannot be written, nor can a value of another kind or a column without a name; an error names the column and the row.

procedure
(csv->table [in]) → table?
in : input-port? = (current-input-port)

Reads a CSV file from in to its end, and returns it as a table.

Examples:

> (require glmnet/data/csv)
> (csv->table (open-input-string "id,dose,treated\nA,2.5,TRUE\n\"B, 2\",5,F\n"))
'(("id" . #("A" "B, 2")) ("dose" . #(2.5 5.0)) ("treated" . #(#t #f)))
> (csv->table (open-input-string "note\n\"said \"\"hi\"\"\"\n\"two\nlines\"\n"))
'(("note" . #("said \"hi\"" "two\nlines")))
> (csv->table (open-input-string "x\n0x1A\n-inf\n 7 \n\" TRUE\"\ntrue\n"))
'(("x" . #(26.0 -inf.0 7.0 " TRUE" "true")))
> (csv->table (open-input-string "x,y\n1,2\n3,NA\n"))
csv->table: the input has a missing value
  column: "y"
  row: 1
  line: 3
> (csv->table (open-input-string "x\n1　\n　\n"))
csv->table: the input has a missing value
  column: "x"
  row: 1
  line: 3
> (csv->table (open-input-bytes #"name\nM\374ller\n"))
csv->table: the input is not UTF-8
  line: 2
  byte offset: 6

procedure
(csv-file->table path) → table?
path : path-string?

Reads the CSV file at path as csv->table reads a port.

Examples:

> (define mtcars-file (collection-file-path "mtcars.csv" "glmnet" "datasets"))
> (map car (csv-file->table mtcars-file))
'("mpg" "cyl" "disp" "hp" "drat" "wt" "qsec" "vs" "am" "gear" "carb")

procedure
(table->csv table [out]) → void?
table : table?
out : output-port? = (current-output-port)

Writes table to out as a CSV file.

Examples:

> (table->csv (list (cons "x" (list 1 0.1 1/3 +inf.0))
                    (cons "label" '("a" "b, c" "42" say))
                    (cons "flag" '(#t #f #t #f))))
x,label,flag
1,a,TRUE
0.1,"b, c",FALSE
0.3333333333333333,"42",TRUE
Inf,say,FALSE
> (define out (open-output-string))
> (table->csv (list (cons "x" (list 0.1 (+ 0.1 0.2) 1e-300))) out)
> (get-output-string out)
"x\n0.1\n0.30000000000000004\n1e-300\n"
> (csv->table (open-input-string (get-output-string out)))
'(("x" . #(0.1 0.30000000000000004 1e-300)))
> (table->csv (csv->table (open-input-string "id,dose\n")))
id,dose
> (table->csv (list (cons "code" '("NA" "b"))))
table->csv: the table has a string that would be read back
as a missing value
  column: "code"
  row: 0
  element: "NA"

procedure
(table->csv-file table path [#:exists exists]) → void?
  table : table?
  path : path-string?
   exists : (or/c 'error 'replace 'truncate 'truncate/replace)
= 'error

Writes table to the file at path as table->csv writes it to a port. exists says what to do when the file exists, as for open-output-file; none of the choices keeps the file’s old contents.

Examples:

> (define path (make-temporary-file "table-~a.csv"))
> (table->csv-file (list (cons "x" '(1 2)) (cons "y" '(3.5 4.5))) path #:exists 'replace)
> (file->string path)
"x,y\n1,3.5\n2,4.5\n"
> (csv-file->table path)
'(("x" . #(1.0 2.0)) ("y" . #(3.5 4.5)))

2.5 Matrices from math/matrix🔗ℹ

(require glmnet/data/math)

package: glmnet

Conversions between the matrices of math/matrix and design matrices, and from math/array arrays to responses. The rows of a matrix are observations and its columns predictors. glmnet does not re-export these bindings, and (require glmnet) does not load math/matrix. See Matrices from math/matrix.

Every array that math/array returns to untyped code carries a contract, and so does the procedure that computes its elements, which checks the index it is called with each time. The conversions’ element loops are written in Typed Racket, so they call that procedure without adding contracts of their own, and they avoid it where they can. The design matrix is written in place, with no intermediate copy:

a flonum array (an FlArray, from array->flarray, flarray or design-matrix->matrix) is copied from its flarray-data in one pass;
a mutable array (a Mutable-Array, from vector->matrix or array->mutable-array) is read from its mutable-array-data;
any other array, such as the result of build-matrix, matrix or matrix*, is read one element at a time through its contracted procedure;
a lazy array, one made while array-strictness is #f or one that array-broadcast or array-lazy returns, which are lazy at the default setting too, is read the same way, with a fresh mutable index vector for each element, because its index transforms, such as those of matrix-transpose and array-slice-ref, write to the vector they are given.

For a large matrix, the first two take about as long as rows->design-matrix takes for the same rows as lists, the third several times as long, and the fourth far longer.

procedure
(matrix->design-matrix M
[ #:column-names column-names])
→ design-matrix?
M : (and/c array? matrix?)
column-names : (or/c #f (listof (or/c string? symbol?))) = #f

A design matrix of the entries of M, one row per row of M. Every entry must be a real, finite number, and exact numbers become flonums; an error names the column of an entry that is not (by its name, when the columns have names), its row, counting from 0, and the entry. column-names names the columns, as for rows->design-matrix, and the names become strings. A design matrix with column names is a table, which the formula front end fits from by name. The response matrix Y of the multi-response Gaussian family converts the same way.

Examples:

> (require math/array math/matrix glmnet/data/math)
> (define M (matrix [[1 2 3] [2 1 5] [3 4 11] [4 3 11] [5 6 17]]))
> (define D (matrix->design-matrix M #:column-names '(x1 x2 y)))
> (design-matrix->rows D)
'((1.0 2.0 3.0) (2.0 1.0 5.0) (3.0 4.0 11.0) (4.0 3.0 11.0) (5.0 6.0 17.0))
> (equal? D (rows->design-matrix (matrix->list* M) #:column-names '(x1 x2 y)))
#t
> (coef (formula-fit (~ y x1 x2) D #:lambda 0))
'(("(Intercept)" . -1.0345797337849323)
  ("x1" . 2.234820972582017)
  ("x2" . 1.1656615050121506))
> (matrix->design-matrix (matrix [[1.0 2.0] [3.0 +nan.0]])
                         #:column-names '(x1 x2))
matrix->design-matrix: the matrix has an element that is not
finite
  column: "x2"
  row: 1
  element: +nan.0

procedure
(design-matrix->matrix dm) → (and/c array? matrix?)
dm : design-matrix?

A matrix of the entries of dm, one row per row of dm: a flonum array, an FlArray, that holds a copy of them. It does not carry dm’s column names, which design-matrix-column-names gives.

Examples:

> (design-matrix->matrix D)
(flarray
#[#[1.0 2.0 3.0]
   #[2.0 1.0 5.0]
   #[3.0 4.0 11.0]
   #[4.0 3.0 11.0]
   #[5.0 6.0 17.0]])
> (equal? (matrix->design-matrix (design-matrix->matrix D)) (matrix->design-matrix M))
#t
> (matrix* (design-matrix->matrix (rows->design-matrix '((1 2) (3 4))))
           (col-matrix [1 -1]))
(array #[#[-1.0] #[-1.0]])

procedure
(array->response A) → (and/c (listof real?) pair?)
   A :
(and/c array?
       (or/c row-matrix?
             col-matrix?
             (property/c array-shape (vector/c exact-positive-integer?))))

The elements of A as a list, the form in which the fit procedures take a response. A is a row matrix, a column matrix or a one-dimensional array with at least one element. Every element must be a real, finite number; an error names the position of one that is not, counting from 0, and the element. The elements are returned as they are, so class labels such as those of multinomial-fit stay exact integers.

Examples:

> (array->response (col-matrix [1 0 1]))
'(1 0 1)
> (array->response (row-matrix [2.5 1/2]))
'(2.5 1/2)
> (array->response (array #[0 2 1]))
'(0 2 1)
> (lasso (matrix->design-matrix M) (array->response (->col-matrix '(1 3 2 5 4)))
         #:lambda 0.1)
#<glmnet:gaussian λ=0.1 dev=0.9170 nz=2/3>
> (array->response (matrix [[1 2] [3 4]]))
array->response: contract violation
  expected: (and/c array? (or/c row-matrix? col-matrix?
(property/c array-shape (vector/c
exact-positive-integer?))))
  given: (array #[#[1 2] #[3 4]])
  in: the 1st argument of
      (->
       (and/c
        array?
        (or/c
         row-matrix?
         col-matrix?
         (property/c
          array-shape
          (vector/c exact-positive-integer?))))
       (non-empty-listof real?))
  contract from: <pkgs>/glmnet/data/math.rkt
  blaming: program
   (assuming the contract is correct)
  at: <pkgs>/glmnet/data/math.rkt:123:3

2.6 Polars dataframes🔗ℹ

(require glmnet/data/polars)

package: glmnet

Conversions between the dataframes of polars and glmnet’s design matrices, responses and tables. glmnet does not re-export them and does not load Polars. See Polars dataframes.

A column that is converted to numbers must have an integer or floating-point dtype; Polars casts it to doubles as it copies it out. Column names are strings or symbols, compared as strings, and must be names of the dataframe’s columns; the contracts check the names and the dtypes. A missing value (a null), anywhere in a column that is converted, is an error naming its column and row, and so is a value that is not finite where numbers are needed. Nothing is dropped or filled in.

procedure
(polars->design-matrix df columns) → design-matrix?
df : dataframe?
columns : (and/c (listof (or/c string? symbol?)) pair?)

A design matrix of the columns of df named by columns, in that order, with their names, as strings, as its column names. The contract requires df to have at least one row, and columns to name distinct columns of df with numeric dtypes. The matrix is Polars’ column-major export, dataframe->f64vector, taken over without a further copy; it shares no memory with df.

Examples:

> (define trial
    (dataframe (list (series '(1 2 3) #:name "dose")
                     (series '(0.5 1.5 2.5) #:name "age")
                     (series '("a" "b" "a") #:name "site"))))
> (define trial-matrix (polars->design-matrix trial '(age "dose")))
> (design-matrix->rows trial-matrix)
'((0.5 1.0) (1.5 2.0) (2.5 3.0))
> (design-matrix-column-names trial-matrix)
'("age" "dose")
> (polars->design-matrix trial '("dose" "site"))
polars->design-matrix: contract violation
  expected: a non-empty list of distinct names of numeric
columns of the dataframe
  given: column "site", of dtype string
  in: the columns argument of
      (->i
       ((df
         (and/c dataframe? dataframe-with-rows/c))
        (columns
         (df)
         (frame-columns/c
          df
          numeric-dtype?
          "numeric")))
       (result design-matrix?))
  contract from: <pkgs>/glmnet/data/polars.rkt
  blaming: program
   (assuming the contract is correct)
  at: <pkgs>/glmnet/data/polars.rkt:22:3

procedure
(design-matrix->polars dm
[ #:column-names column-names])
→ dataframe?
  dm : design-matrix?
   column-names : (listof (or/c string? symbol?))
=
(or (design-matrix-column-names dm)
    (list "V1" "V2" ...))

A dataframe of the columns of dm, each a 'float64 series, named by column-names: by default, dm’s column names, or "V1", "V2", …, as R names the columns of a matrix, when it has none. The contract requires one distinct name per column. Polars dataframes says why this direction is the slower one.

Examples:

> (design-matrix->polars trial-matrix)
shape: (3, 2)
┌─────┬──────┐
│ age ┆ dose │
│ --- ┆ ---  │
│ f64 ┆ f64  │
╞═════╪══════╡
│ 0.5 ┆ 1.0  │
│ 1.5 ┆ 2.0  │
│ 2.5 ┆ 3.0  │
└─────┴──────┘
> (column-names (design-matrix->polars (rows->design-matrix '((1 2)))))
'("V1" "V2")
> (column-names (design-matrix->polars trial-matrix #:column-names '(a b)))
'("a" "b")

procedure
(polars->response df column) → (and/c (listof real?) pair?)
df : dataframe?
column : (or/c string? symbol?)

The values of the column of df named column as a response: exact integers from an integer column, flonums from a floating-point one. The contract requires df to have at least one row, and column to name a column of df with a numeric dtype.

Examples:

> (polars->response trial "dose")
'(1 2 3)
> (polars->response (dataframe (list (series (list 1.0 polars-null 3.0)
                                             #:name "y")))
                    "y")
polars->response: the dataframe has a missing value
  column: "y"
  row: 1

procedure
(polars->table df [columns]) → table?
df : dataframe?
columns : (and/c (listof (or/c string? symbol?)) pair?)
= (column-names df)

A table of the columns of df named by columns, in that order: an association list from each name to a vector of the column’s values. Numeric columns hold numbers, exact integers from an integer column, and boolean columns booleans. String columns hold strings, and categorical and enum columns symbols, which the formula front end reads as factors. A factor’s levels are sorted as strings, so the order of an enum’s categories is not kept (see Polars dataframes). The contract requires df to have at least one row. When columns is given, it must name distinct columns of df with those dtypes; when it is not, every column must have one of them.

Examples:

> (polars->table trial)
'(("dose" . #(1 2 3)) ("age" . #(0.5 1.5 2.5)) ("site" . #("a" "b" "a")))
> (polars->table trial '("site"))
'(("site" . #("a" "b" "a")))

procedure
(table->polars t [columns]) → dataframe?
t : table?
columns : (and/c (listof (or/c string? symbol?)) pair?)
= (table-column-names t)

A dataframe of the columns of t named by columns, in that order. A column’s values choose its dtype:

'int64 for exact integers from −2⁶³ to 2⁶³ − 1;
'uint64 for exact integers from 0 to 2⁶⁴ − 1, when some are 2⁶³ or more;
'float64 for any other reals, and for integers mixed with them;
'boolean for booleans, 'categorical for symbols, and 'string for strings, or for strings and symbols mixed.

The contract requires columns to name distinct columns of t. An exact integer outside both ranges, any other exact number too large for a flonum, a column of integers that needs both (a negative one and one of 2⁶³ or more), and a column whose values no one dtype holds are errors naming the column, the row and the element.

Examples:

> (define cars (table->polars mtcars '("mpg" "cyl" "wt")))
> (map (lambda (name) (dtype (ref cars name))) (column-names cars))
'(float64 float64 float64)
> (table->polars (list (cons "id" '(a b a)) (cons "x" '(1 2.5 3))))
shape: (3, 2)
┌─────┬─────┐
│ id  ┆ x   │
│ --- ┆ --- │
│ cat ┆ f64 │
╞═════╪═════╡
│ a   ┆ 1.0 │
│ b   ┆ 2.5 │
│ a   ┆ 3.0 │
└─────┴─────┘
> (dtype (ref (table->polars (list (cons "n" (list 1 (expt 2 63))))) "n"))
'uint64
> (table->polars (list (cons "x" '(1 "two"))))
table->polars: the table has a column whose values no Polars
dtype holds
  column: "x"
  row: 1
  element: "two"

2.7 Example datasets🔗ℹ

(require glmnet/datasets)

package: glmnet

glmnet/datasets provides the example datasets of R’s glmnet 4.1.10, which its vignettes use, and R’s mtcars and iris, which the formula examples use. glmnet does not re-export it. See Example datasets.

A dataset is a CSV file in the package, under "glmnet/datasets/", which "scripts/export-datasets.R" writes from R with 17 significant digits, so that every number reads back as R’s double. R glmnet’s datasets have a procedure each, which reads its file on its first call and returns the same values on every call. The values are the arguments of the family’s fitter, in order: the predictors as a design matrix whose columns are named "V1", "V2", and so on, as R’s coef names the columns of these unnamed matrices, and then the response, in the shape the family takes (see Data). mtcars and iris are tables, read when the module is instantiated. Every module that requires them shares them, so their columns are immutable vectors; csv-file->table reads a fresh copy whose columns can be changed.

procedure
(quick-start-example) →
design-matrix? (listof flonum?)

R’s QuickStartExample, the data of the vignette’s Quick Start: 100 observations of 20 predictors and a numeric response, for elnet-fit and its relatives. See Quick start.

Examples:

> (require glmnet/datasets)
> (define-values (x y) (quick-start-example))
> x
#<design-matrix 100x20>
> (length y)
100
> (lasso x y #:lambda 0.1)
#<glmnet:gaussian λ=0.1 dev=0.8994 nz=9/20>

procedure
(binomial-example) →
design-matrix? (listof (or/c 0 1))

R’s BinomialExample: 100 observations of 30 predictors and a 0/1 response, for logistic-fit and its relatives.

Examples:

> (define-values (bx by) (binomial-example))
> (list (design-matrix-nrows bx) (design-matrix-ncols bx))
'(100 30)
> (for/sum ([label (in-list by)]) label)
56

procedure
(multinomial-example) →
design-matrix? (listof (or/c 0 1 2))

R’s MultinomialExample: 500 observations of 30 predictors and a class label, for multinomial-fit and its relatives. R’s classes are 1, 2 and 3; they are 0, 1 and 2 here, the labels multinomial-fit takes.

Examples:

> (define-values (mx my) (multinomial-example))
> (for/list ([k (in-range 3)])
(for/sum ([label (in-list my)]) (if (= label k) 1 0)))
'(142 174 184)

procedure
(poisson-example) →
design-matrix?
(listof exact-nonnegative-integer?)

R’s PoissonExample: 500 observations of 20 predictors and a count, for poisson-fit and its relatives.

Examples:

> (define-values (px py) (poisson-example))
> (apply max py)
395

procedure
(cox-example) →
design-matrix?
(listof (and/c flonum? positive?))
(listof (or/c 0 1))

R’s CoxExample: 1000 observations of 30 predictors, and the survival times and statuses, R’s columns time and status, for cox-fit and its relatives, which take them as two arguments. A status is 1 for a death and 0 for a censored time.

Examples:

> (define-values (cx time status) (cox-example))
> (for/sum ([s (in-list status)]) s)
692
> (cox-path cx time status #:nlambda 5)
#<glmnet-path:cox
Df %Dev Lambda
1 0 0.00 0.236800
2 13 5.62 0.023680
3 25 5.87 0.002368
4 29 5.87 0.000237
5 30 5.87 0.000024>

procedure
(multi-gaussian-example) →
design-matrix? design-matrix?

R’s MultiGaussianExample: 100 observations of 20 predictors and four numeric responses, for mgaussian-fit and its relatives. The responses are a design matrix whose columns are named "y1" to "y4", as R’s coef names them.

Examples:

> (define-values (gx gy) (multi-gaussian-example))
> (design-matrix-column-names gy)
'("y1" "y2" "y3" "y4")

procedure
(sparse-example) →
design-matrix? (listof flonum?)

R’s SparseExample: 100 observations of 20 predictors, 84% of whose entries are zero, and a numeric response. R holds the predictors as a sparse matrix; here they are a dense design matrix, until sparse input is supported (#11).

Examples:

> (define-values (sx sy) (sparse-example))
> (for*/sum ([row (in-list (design-matrix->rows sx))] [v (in-list row)])
(if (zero? v) 1 0))
1678

value
mtcars : table?

R’s datasets::mtcars, from the 1974 Motor Trend road tests of 32 cars, as an association list from each of R’s eleven column names to its column, an immutable vector: "mpg", "cyl", "disp", "hp", "drat", "wt", "qsec", "vs", "am", "gear" and "carb", in R’s order, with the cars in R’s order, from the Mazda RX4 to the Volvo 142E. R’s row names, the cars’ models, are not a column.

Examples:

> (table-column-names mtcars)
'("mpg" "cyl" "disp" "hp" "drat" "wt" "qsec" "vs" "am" "gear" "carb")
> (cdr (assoc "wt" mtcars))
'#(2.62
   2.875
   2.32
   3.215
   3.44
   3.46
   3.57
   3.19
   3.15
   3.44
   3.44
   4.07
   3.73
   3.78
   5.25
   5.424
   5.345
   2.2
   1.615
   1.835
   2.465
   3.52
   3.435
   3.84
   3.845
   1.935
   2.14
   1.513
   3.17
   2.77
   3.57
   2.78)
> (vector-set! (cdr (assoc "wt" mtcars)) 0 3.0)
vector-set!: contract violation
  expected: (and/c vector? (not/c immutable?))
  given: '#(2.62 2.875 2.32 3.215 3.44 3.46 3.57 3.19 3.15
3.44 3.44 4.07 3.73 3.78 5.25 5.424 5.345 2.2 1.615 1.835
2.465 3.52 3.435 3.84 3.845 1.935 2.14 1.513 3.17 2.77 3.57
2.78)

value
iris : table?

R’s datasets::iris, Anderson’s measurements of 150 irises, 50 of each of three species, as an association list from each of R’s five column names to its column, an immutable vector: "Sepal.Length", "Sepal.Width", "Petal.Length" and "Petal.Width" in centimetres, and "Species", whose values are the strings "setosa", "versicolor" and "virginica". R holds the species as a factor with these levels, which is also the order that sorting the strings gives. The flowers are in R’s order.

Examples:

> (table-column-names iris)
'("Sepal.Length" "Sepal.Width" "Petal.Length" "Petal.Width" "Species")
> (formula-predictor-names (Sepal.Length . ~ . Petal.Width + Species) iris)
'("Petal.Width" "Speciesversicolor" "Speciesvirginica")

2.8 Gaussian models🔗ℹ

The Gaussian family. The four named models are elnet-fit with a fixed #:alpha. See Ordinary least squares (λ = 0), Ridge regression (L2, α = 0), Lasso (L1, α = 1) and Elastic net (0 < α < 1).

struct
(struct elnet-result ( intercept
coefficients
r-squared
lambda
num-passes)
    #:transparent)
  intercept : real?
  coefficients : (vectorof real?)
  r-squared : real?
  lambda : real?
  num-passes : exact-nonnegative-integer?

A fitted Gaussian model. coefficients has one entry per column of X, on the original predictor scale; r-squared is the fraction of variance explained; lambda is the penalty the solver used; num-passes is the number of coordinate-descent passes.

Like every result type, it prints as a summary of its family, λ, deviance ratio and number of nonzero coefficients (see Printing), and it implements gen:glmnet-model.

Examples:

> (define X '((1.0 2.0 1.0) (2.0 1.0 4.0) (3.0 4.0 9.0)
(4.0 3.0 16.0) (5.0 6.0 25.0) (6.0 5.0 36.0)))
> (define y '(1.0 4.0 3.0 6.0 5.0 8.0))
> (define fit (lasso X y #:lambda 0.05))
> fit
#<glmnet:gaussian λ=0.05 dev=0.9941 nz=2/3>
> (elnet-result-intercept fit)
0.9999999999999996
> (elnet-result-coefficients fit)
'#(1.8292174872340037 -0.8292174872340038 0.0)

procedure
(elnet-fit X
y
[ #:predictors predictors]
#:lambda lambda
[ #:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters]) → elnet-result?
  X : data/c
  y : (response-for/c X real?)
  predictors : (predictors-for/c X y) = #f
  lambda : (>=/c 0)
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Fits a Gaussian elastic-net model of the response y, one real per row of X, at a single lambda. X and y are unnamed data, or named data with the response and predictors named, as in Data arguments. As in R, a constant y (all zero, when intercept? is #f) has nothing to standardize and raises exn:fail. The four models below call elnet-fit, and its errors name the one called.

Examples:

> (elnet-fit X y #:alpha 0.5 #:lambda 0.5)
#<glmnet:gaussian λ=0.5 dev=0.7838 nz=2/3>
> (elnet-fit autos "mpg" #:predictors '("wt" "hp") #:alpha 0.5 #:lambda 0.5)
#<glmnet:gaussian λ=0.5 dev=0.8434 nz=2/2>
> (lasso X '(2.0 2.0 2.0 2.0 2.0 2.0) #:lambda 0.5)
lasso: y is constant; gaussian glmnet fails at
standardization step

procedure
(ols X
y
[ #:predictors predictors
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters]) → elnet-result?
  X : data/c
  y : (response-for/c X real?)
  predictors : (predictors-for/c X y) = #f
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-10
  max-iters : exact-positive-integer? = 100000

Ordinary least squares: elnet-fit with #:lambda 0.0, where #:alpha has no effect. The default thresh is tighter than the penalized fits’ because coordinate descent approaches the unpenalized solution slowly.

Examples:

> (elnet-result-coefficients
(ols '((1.0 2.0) (2.0 1.0) (3.0 4.0) (4.0 3.0) (5.0 6.0))
'(1.0 4.0 3.0 6.0 5.0)))
'#(1.9999829127580482 -0.9999884545662485)
> (elnet-result-coefficients (ols autos "mpg" #:predictors '("wt" "hp")))
'#(-2.5190175381213304 -0.030876933077271105)

procedure
(ridge X
y
[ #:predictors predictors]
#:lambda lambda
[ #:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters]) → elnet-result?
  X : data/c
  y : (response-for/c X real?)
  predictors : (predictors-for/c X y) = #f
  lambda : (>=/c 0)
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Ridge regression: elnet-fit with #:alpha 0.0. Shrinks every coefficient toward zero as lambda grows, but sets none exactly to zero.

Examples:

> (elnet-result-coefficients (ridge X y #:lambda 0.1))
'#(1.1614345231080536 -0.7532810830027743 0.08306586531538782)
> (elnet-result-coefficients (ridge autos "mpg" #:predictors '("wt" "hp") #:lambda 1.0))
'#(-2.2279325497635045 -0.02388297752938169)

procedure
(lasso X
y
[ #:predictors predictors]
#:lambda lambda
[ #:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters]) → elnet-result?
  X : data/c
  y : (response-for/c X real?)
  predictors : (predictors-for/c X y) = #f
  lambda : (>=/c 0)
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

The lasso: elnet-fit with #:alpha 1.0. Sets coefficients exactly to zero, more of them as lambda grows.

Examples:

> (elnet-result-coefficients (lasso X y #:lambda 0.5))
'#(0.8786585495440113 0.0 0.0)
> (elnet-result-coefficients (lasso autos "mpg" #:predictors '("wt" "hp") #:lambda 1.0))
'#(-1.2137877816701421 -0.019538683227314706)

procedure
(elastic-net X
y
[ #:predictors predictors]
#:alpha alpha
#:lambda lambda
[ #:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters]) → elnet-result?
  X : data/c
  y : (response-for/c X real?)
  predictors : (predictors-for/c X y) = #f
  alpha : (real-in 0 1)
  lambda : (>=/c 0)
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

The elastic net at an explicit alpha, which is required here. #:alpha 0.0 is ridge and #:alpha 1.0 is lasso.

Examples:

> (elnet-result-coefficients (elastic-net X y #:alpha 0.5 #:lambda 0.5))
'#(0.5773773035370475 0.0 0.054686809526739884)
> (elnet-result-coefficients
(elastic-net autos "mpg" #:predictors '("wt" "hp") #:alpha 0.5 #:lambda 1.0))
'#(-1.8006845871692458 -0.02166964237447535)

procedure
(elnet-predict fit X) → (listof real?)
fit : elnet-result?
X : data/c

The fitted value β₀ + xβ for each row of X: predict with its defaults. A fit from named data reads named X by its predictors’ names.

Examples:

> (elnet-predict fit '((7.0 6.0 49.0) (0.0 0.0 0.0)))
'(8.829217487234002 0.9999999999999996)
> (elnet-predict car-fit (list (cons "wt" '(3.0 2.5)) (cons "hp" '(150 100))))
'(19.326669351755836 22.130024774680052)

2.9 Binomial models🔗ℹ

The binomial family: two-class logistic regression on 0/1 labels. See Binomial logistic regression (classification).

struct
(struct logistic-result ( intercept
coefficients
dev-ratio
lambda
num-passes)
    #:transparent)
  intercept : real?
  coefficients : (vectorof real?)
  dev-ratio : real?
  lambda : real?
  num-passes : exact-nonnegative-integer?

A fitted two-class model. intercept and coefficients are on the log-odds scale for class 1; dev-ratio is the fraction of null deviance explained.

Examples:

> (require glmnet/datasets)
> (define X '((1.0 5.0 2.0) (2.0 6.0 1.0) (2.0 5.0 3.0) (1.0 4.0 1.0)
(6.0 2.0 2.0) (5.0 1.0 1.0) (6.0 1.0 3.0) (5.0 2.0 1.0)))
> (define y '(0 0 0 0 1 1 1 1))
> (define fit (logistic-fit X y #:lambda 0.05))
> (logistic-result-coefficients fit)
'#(0.9597305669295235 -0.5738296629445224 0.0)
> (logistic-result-dev-ratio fit)
0.9168013564414029

procedure
(logistic-fit X
y
[ #:predictors predictors]
#:lambda lambda
[ #:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters]) → logistic-result?
  X : data/c
  y : (response-for/c X (or/c 0 1) #:classes? #t)
  predictors : (predictors-for/c X y #:classes? #t) = #f
  lambda : (>=/c 0)
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Fits a two-class logistic elastic-net model of the labels y, 0 and 1, or two class labels (see Data arguments), the second of which is class 1. If a class probability collapses, typically under perfect separation, the exn:fail exception is raised; a larger lambda usually fixes it.

Examples:

> (logistic-fit X y #:lambda 0.05)
#<glmnet:binomial λ=0.05 dev=0.9168 nz=2/3>
> (define cars+ (cons (cons "heavy" (for/list ([wt (in-vector (cdr (assoc "wt" mtcars)))])
                                      (if (> wt 3.3) "yes" "no")))
                      mtcars))
> (define heavy-fit (logistic-fit cars+ "heavy" #:predictors '("mpg" "hp") #:lambda 0.05))
> (logistic-predict heavy-fit (hash "mpg" '(15.0 30.0) "hp" '(200 70)))
'("yes" "no")
> (logistic-fit iris "Species" #:lambda 0.05
                #:predictors '("Petal.Length" "Petal.Width"))
logistic-fit: a binomial response has two classes; the
multinomial family takes more
  column: "Species"
  classes: '("setosa" "versicolor" "virginica")

procedure
(logistic-predict-proba fit X) → (listof (real-in 0 1))
fit : logistic-result?
X : data/c

The class-1 probability 1 / (1 + exp(−(β₀ + xβ))) for each row of X: predict with #:type 'response.

Example:

> (logistic-predict-proba fit '((2.0 5.0 2.0) (5.0 2.0 2.0)))
'(0.0829824131519593 0.9000862010987204)

procedure
(logistic-predict fit
X
[ #:threshold threshold])
→ (listof (or/c 0 1 string?))
  fit : logistic-result?
  X : data/c
  threshold : (real-in 0 1) = 0.5

Hard labels: 1 where logistic-predict-proba is at least threshold, otherwise 0, or the classes’ labels for a fit of a response of labels. At the default threshold this is predict with #:type 'class, except for a row whose probability is exactly 0.5, which R and predict label 0.

Example:

> (logistic-predict fit '((2.0 5.0 2.0) (5.0 2.0 2.0)))
'(0 1)

2.10 Multinomial models🔗ℹ

The multinomial family: K-class logistic regression on integer labels. See Multinomial classification (K classes).

struct
(struct multinomial-result ( intercepts
coefficients
dev-ratio
lambda
num-passes)
    #:transparent)
  intercepts : (vectorof real?)
  coefficients : (vectorof (vectorof real?))
  dev-ratio : real?
  lambda : real?
  num-passes : exact-nonnegative-integer?

A fitted K-class model. intercepts holds one real per class and coefficients one coefficient vector per class, each with one entry per predictor. Adding the same constant to every intercept leaves the probabilities unchanged, so, as R does, the intercepts are centred to sum to zero. dev-ratio is the fraction of null deviance explained.

Examples:

> (require glmnet/datasets)
> (define X '((1.0 1.0) (2.0 1.0) (5.0 1.0) (6.0 1.0) (3.0 5.0) (4.0 6.0)))
> (define y '(0 0 1 1 2 2))
> (define fit (multinomial-fit X y #:lambda 0.05))
> (multinomial-result-coefficients fit)
'#(#(-0.6863780549780656 0.0)
#(0.8092663108066648 0.0)
#(0.0 1.140531561288397))

procedure
(multinomial-fit X
y
[ #:predictors predictors]
#:lambda lambda
[ #:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters])
→ multinomial-result?
  X : data/c
  y : (response-for/c X (and/c integer? (>=/c 0)) #:classes? #t)
  predictors : (predictors-for/c X y #:classes? #t) = #f
  lambda : (>=/c 0)
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Fits a K-class multinomial elastic-net model. The labels y are integers, exact or inexact as in an flvector, and must cover 0 to K−1 with every class present; otherwise the exn:fail exception is raised. They may instead be class labels, at least two (see Data arguments). As with logistic-fit, a collapsed class probability raises exn:fail.

Examples:

> (multinomial-result-intercepts (multinomial-fit X y #:lambda 0.05))
'#(3.497091517940383 -1.7181551950723566 -1.778936322868027)
> (multinomial-result-intercepts (multinomial-fit X '(a a b b c c) #:lambda 0.05))
'#(3.497091517940383 -1.7181551950723566 -1.778936322868027)
> (multinomial-result-intercepts
(multinomial-fit iris "Species" #:predictors '("Petal.Length" "Petal.Width") #:lambda 0.05))
'#(4.756583464635003 0.3567756057814526 -5.113359070416457)
> (multinomial-fit X '(0 0 2 2 2 2) #:lambda 0.05)
multinomial-fit: class 1 has no observations; labels must
cover 0..2 contiguously

procedure
(multinomial-predict-proba fit X)
→ (listof (listof (real-in 0 1)))
fit : multinomial-result?
X : data/c

The softmax class probabilities for each row of X: one list of K entries, summing to 1, per row. This is predict with #:type 'response.

Example:

> (multinomial-predict-proba fit '((1.5 1.0) (3.5 5.5)))
'((0.912412962930536 0.046726550367775885 0.04086048670168831)
(0.03128871441725081 0.03190510530876551 0.9368061802739837))

procedure
(multinomial-predict fit X)
→ (listof (or/c exact-nonnegative-integer? string?))
fit : multinomial-result?
X : data/c

The most probable class for each row of X, or its label for a fit of a response of labels: predict with #:type 'class. On a tie the lowest class wins.

Example:

> (multinomial-predict fit '((1.5 1.0) (5.5 1.0) (3.5 5.5)))
'(0 1 2)

2.11 Cox models🔗ℹ

The Cox family: proportional-hazards survival models. There is no intercept, and so no #:intercept? keyword. See Cox proportional hazards (survival).

struct
(struct cox-result (coefficients dev-ratio lambda num-passes)
    #:transparent)
  coefficients : (vectorof real?)
  dev-ratio : real?
  lambda : real?
  num-passes : exact-nonnegative-integer?

A fitted Cox model. coefficients are on the log-hazard-ratio scale; dev-ratio is the fraction of null partial-likelihood deviance explained.

Examples:

> (define X '((0.5 1.0) (1.0 2.0) (1.5 1.0) (2.0 2.0)
(2.5 1.0) (3.0 2.0) (3.5 1.0) (4.0 2.0)))
> (define times '(12.0 10.0 11.0 8.0 6.0 7.0 4.0 3.0))
> (define statuses '(0 0 0 1 1 1 1 1))
> (define fit (cox-fit X times statuses #:lambda 0.1))
> (cox-result-coefficients fit)
'#(1.9229529670643517 0.0)

procedure
(cox-fit X
y
[ statuses
#:predictors predictors]
#:lambda lambda
[ #:alpha alpha
#:standardize? standardize?
#:thresh thresh
#:max-iters max-iters]) → cox-result?
  X : data/c
  y : (survival-for/c X)
  statuses : (statuses-for/c X y) = none
  predictors : (predictors-for/c X y) = #f
  lambda : (>=/c 0)
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Fits a Cox proportional-hazards elastic-net model of positive follow-up times and the matching event indicators: 1 or #t for an observed event, 0 or #f for right-censoring. For unnamed data, y is the times and statuses, then required, the indicators; for named data, y names the time and status columns, and there is no statuses argument. If no status is 1, the exn:fail exception is raised.

Examples:

> (cox-fit X times statuses #:lambda 0.5)
#<glmnet:cox λ=0.5 dev=0.2367 nz=1/2>
> (define patients (list (cons "age" '(50 61 45 70 58 66 39 72))
                         (cons "dose" '(1.0 2.0 1.0 2.0 1.0 2.0 1.0 2.0))
                         (cons "months" times)
                         (cons "died" statuses)))
> (cox-fit patients '("months" "died") #:predictors '("age" "dose") #:lambda 0.05)
#<glmnet:cox λ=0.05 dev=0.0385 nz=1/2>
> (cox-fit patients '("months") #:predictors '("age") #:lambda 0.5)
cox-fit: contract violation
  expected: a list of the names of two columns of the table,
the time and the status
  given: '("months"), a list of one name
  in: the y argument of
      (->*
       (data/c
        (survival-for/c X)
        #:lambda
        (>=/c 0))
       ((statuses-for/c X y)
        #:predictors
        (predictors-for/c X y)
        ...)
       cox-result?)
  contract from: <pkgs>/glmnet/core/cox.rkt
  blaming: program
   (assuming the contract is correct)
  at: <pkgs>/glmnet/core/cox.rkt:32:3
> (cox-fit X times '(0 0 0 0 0 0 0 0) #:lambda 0.1)
cox-fit: at least one observation must be an event (status =
1)

procedure
(cox-linear-predictor fit X) → (listof real?)
fit : cox-result?
X : data/c

The log relative hazard xβ for each row of X: predict with its defaults.

Example:

> (cox-linear-predictor fit '((1.0 1.0) (3.0 1.0)))
'(1.9229529670643517 5.768858901193055)

procedure
(cox-relative-risk fit X) → (listof (>/c 0))
fit : cox-result?
X : data/c

The relative risk exp(xβ) for each row of X: the factor by which the row’s hazard exceeds the baseline hazard. This is predict with #:type 'response.

Example:

> (cox-relative-risk fit '((1.0 1.0) (3.0 1.0)))
'(6.8411303037210045 320.17217603082736)

2.12 Poisson models🔗ℹ

The Poisson family: counts with a log link. See Poisson regression (counts).

struct
(struct poisson-result ( intercept
coefficients
dev-ratio
lambda
num-passes)
    #:transparent)
  intercept : real?
  coefficients : (vectorof real?)
  dev-ratio : real?
  lambda : real?
  num-passes : exact-nonnegative-integer?

A fitted Poisson model. intercept and coefficients are on the log-mean scale; dev-ratio is the fraction of null deviance explained.

Examples:

> (require glmnet/datasets)
> (define X '((1.0 2.0) (2.0 1.0) (3.0 2.0) (4.0 1.0)
(5.0 2.0) (6.0 1.0) (7.0 2.0) (8.0 1.0)))
> (define y '(1 2 2 3 4 6 8 11))
> (define fit (poisson-fit X y #:lambda 0.2))
> (poisson-result-intercept fit)
-0.026590920441019072
> (poisson-result-coefficients fit)
'#(0.29703115403010283 0.0)

procedure
(poisson-fit X
y
[ #:predictors predictors]
#:lambda lambda
[ #:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters]) → poisson-result?
  X : data/c
  y : (response-for/c X (>=/c 0))
  predictors : (predictors-for/c X y) = #f
  lambda : (>=/c 0)
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Fits a Poisson elastic-net model of the non-negative response y, which need not be integral. At least one value must be positive; an all-zero response raises exn:fail before fitting (R warns and returns an empty model).

Examples:

> (poisson-fit X y #:lambda 0.5)
#<glmnet:poisson λ=0.5 dev=0.9596 nz=1/2>
> (poisson-fit mtcars "carb" #:predictors '("hp" "wt") #:lambda 0.1)
#<glmnet:poisson λ=0.1 dev=0.5426 nz=1/2>
> (poisson-fit X '(0 0 0 0 0 0 0 0) #:lambda 0.5)
poisson-fit: the response has no positive count; Poisson
needs at least one y > 0

procedure
(poisson-predict-mean fit X) → (listof (>/c 0))
fit : poisson-result?
X : data/c

The fitted mean exp(β₀ + xβ) for each row of X: predict with #:type 'response.

Example:

> (poisson-predict-mean fit '((2.0 1.0) (9.0 1.0)))
'(1.7638014377572937 14.107258692835407)

2.13 Multi-response Gaussian models🔗ℹ

The multi-response Gaussian family: several numeric responses fitted jointly under a grouped penalty. See Multi-response Gaussian (grouped).

struct
(struct mgaussian-result ( intercepts
coefficients
r-squared
lambda
num-passes)
    #:transparent)
  intercepts : (vectorof real?)
  coefficients : (vectorof (vectorof real?))
  r-squared : real?
  lambda : real?
  num-passes : exact-nonnegative-integer?

A fitted multi-response model. intercepts holds one real per response and coefficients one coefficient vector per response, each with one entry per predictor. r-squared is the fraction of variance explained across all responses.

Examples:

> (require glmnet/datasets)
> (define X '((1.0 2.0) (2.0 1.0) (3.0 2.0) (4.0 1.0) (5.0 2.0) (6.0 1.0)))
> (define Y '((3.0 9.0) (5.0 8.0) (7.0 7.0) (9.0 6.0) (11.0 5.0) (13.0 4.0)))
> (define fit (mgaussian-fit X Y #:lambda 0.1))
> (mgaussian-result-intercepts fit)
'#(1.1833030277982335 9.908348486100884)
> (mgaussian-result-coefficients fit)
'#(#(1.9476277063433618 0.0) #(-0.9738138531716809 0.0))

procedure
(mgaussian-fit X
Y
[ #:predictors predictors]
#:lambda lambda
[ #:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters]) → mgaussian-result?
  X : data/c
  Y : (responses-for/c X)
  predictors : (predictors-for/c X Y) = #f
  lambda : (>=/c 0)
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Fits a multi-response Gaussian elastic-net model. Y is a matrix with one row per observation and one column per response, or, for named data, the names of the response columns. With alpha above zero, the grouped lasso keeps or drops each predictor for every response at once. A constant column is fitted by its intercept alone, but when every column is constant (all zero, when intercept? is #f) there is nothing to fit and the exn:fail exception is raised, as for elnet-fit.

Examples:

> (mgaussian-fit X Y #:lambda 0.5)
#<glmnet:mgaussian λ=0.5 dev=0.9829 nz=1/2>
> (mgaussian-result-coefficients
(mgaussian-fit mtcars '("mpg" "qsec") #:predictors '("wt" "hp") #:lambda 0.5))
'#(#(-3.4767908843263777 -0.029324767934641435)
#(0.4859581017233457 -0.018998204010102826))

procedure
(mgaussian-predict fit X) → (listof (listof real?))
fit : mgaussian-result?
X : data/c

The predictions a0_r + xβ_r for each row of X: one list per row, with one entry per response. This is predict with its defaults.

Example:

> (mgaussian-predict fit '((7.0 1.0) (8.0 2.0)))
'((14.816696972201767 3.0916515138991176)
(16.76432467854513 2.117837660727437))

2.14 Regularization paths🔗ℹ

A regularization path fits a decreasing sequence of λ in one call. Every family has a path fitter, and they all return a glmnet-path. Each fitter takes its family’s data arguments and keywords, with #:lambda made optional:

#:lambda is a list of penalties, fitted largest first. When it is #f (the default), glmnet chooses the sequence as R does: #:nlambda values from λ_max, where every coefficient is zero, down to #:lambda-min-ratio times λ_max. The ratio defaults to 0.01 when there are fewer observations than predictors, and to 0.0001 otherwise; glmnet raises a ratio below 1e-6, including 0, to 1e-6. The first value of an automatic sequence is the extrapolation R’s glmnet reports.
A path can hold fewer λ than asked for, as in R. An automatic sequence stops early once another λ would barely change the fit; the rule depends on the family (below). A binomial or multinomial path, automatic or not, stops where the fitted probabilities saturate at 0 and 1. And any path ends where glmnet fails at one of its λ, for example by not converging within #:max-iters passes: it keeps the λ before that one and logs a warning with the topic 'glmnet (shown with PLTSTDERR="warning@glmnet"), where R warns. The warning names the procedure called: the path fitter, or the cross-validation or formula procedure that called it, with the fold whose training data it was fitting. When glmnet fails at the first λ, the fitter raises exn:fail instead (R returns an empty model).

glmnet’s early-stopping rules apply only to an automatic sequence, and only from its fifth value on. It stops at the λ where, writing D for the deviance ratio:

Gaussian: D gains less than 1e-5 of its own value over the previous λ, or exceeds 0.999.
Multi-response Gaussian: the residual sum of squares falls by less than 1e-5 of its own value, or D exceeds 0.999.
Binomial and multinomial: D gains less than 1e-5 over the previous λ, or exceeds 0.999.
Poisson: D gains less than 0.0001 of its own value over the previous four λ, or exceeds 0.999.
Cox: D gains less than 0.001 of its own value over the previous four λ, or exceeds 0.99.

These are R’s glmnet.control defaults (fdev = 1e-5, devmax = 0.999, mnlam = 5) as each solver applies them.

struct
(struct glmnet-path ( family
lambda
intercepts
coefficients
dev-ratio
df
num-passes)
    #:transparent)
  family : (or/c 'gaussian 'binomial 'multinomial 'cox 'poisson 'mgaussian)
  lambda : (vectorof real?)
  intercepts : (or/c #f vector?)
  coefficients : vector?
  dev-ratio : (vectorof real?)
  df : (vectorof exact-nonnegative-integer?)
  num-passes : exact-nonnegative-integer?

A fitted path. lambda holds the fitted penalties, decreasing, and every other per-λ field has one entry for each of them:

intercepts holds a real per λ, or a vector of one real per class or response for the multinomial and multi-response families. Multinomial intercepts are centred to sum to zero, as in multinomial-result. It is #f for Cox, which has no intercept.
coefficients holds a dense vector per λ with one entry per predictor, or a vector of such vectors (one per class or response).
dev-ratio is the fraction of null deviance explained.
df counts the predictors with a nonzero coefficient, in any class or response.

num-passes counts the coordinate-descent passes over the whole path.

A path prints as R prints one: a table with, for each fitted λ, the number of nonzero coefficients (Df), the percentage of null deviance explained (%Dev) and λ itself (see Printing). predict and coef evaluate a path at any λ.

Examples:

> (require glmnet/datasets)
> (define X '((1.0 2.0 1.0) (2.0 1.0 4.0) (3.0 4.0 9.0)
              (4.0 3.0 16.0) (5.0 6.0 25.0) (6.0 5.0 36.0)))
> (define y '(1.0 4.0 3.0 6.0 5.0 8.0))
> (define path (elnet-path X y #:lambda '(1.0 0.1 0.01)))
> path
#<glmnet-path:gaussian
  Df  %Dev Lambda
1  1 61.07   1.00
2  2 97.63   0.10
3  3 99.98   0.01>
> (glmnet-path-lambda path)
'#(1.0 0.1 0.01)
> (glmnet-path-coefficients path)
'#(#(0.5858885276594514 0.0 0.0)
   #(1.6584349744677054 -0.6584349744677581 0.0)
   #(1.9597271819899955 -0.9658434974467867 0.0008200416386725593))
> (glmnet-path-df path)
'#(1 2 3)

procedure
(elnet-path X
y
[ #:predictors predictors
#:lambda lambda
#:nlambda nlambda
#:lambda-min-ratio lambda-min-ratio
#:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters]) → glmnet-path?
  X : data/c
  y : (response-for/c X real?)
  predictors : (predictors-for/c X y) = #f
  lambda : (or/c #f (and/c (listof (>=/c 0)) pair?)) = #f
  nlambda : exact-positive-integer? = 100
   lambda-min-ratio : (or/c #f (and/c real? (>=/c 0) (</c 1)))
= #f
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

The Gaussian path, as elnet-fit fits one point of it.

Examples:

> (vector-length (glmnet-path-lambda (elnet-path X y)))
51
> (glmnet-path-df (elnet-path X y #:alpha 0.0 #:nlambda 5))
'#(3 3 3 3 3)
> (glmnet-path-lambda (elnet-path X y #:nlambda 5 #:lambda-min-ratio 0.1))
'#(2.000595149544493
   1.1250173275642348
   0.6326437348445768
   0.35576171622587116
   0.2000595149544493)
> (glmnet-path-df (elnet-path autos "mpg" #:predictors '("wt" "hp") #:nlambda 5))
'#(0 2 2 2 2)
> (elnet-path X y #:lambda '(0.1) #:max-iters 1)
elnet-path: glmnet fitted no lambda: convergence was not
reached at the first lambda within #:max-iters passes; try a
larger #:max-iters (jerr=-1)

procedure
(logistic-path X
y
[ #:predictors predictors
#:lambda lambda
#:nlambda nlambda
#:lambda-min-ratio lambda-min-ratio
#:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters])
→ glmnet-path?
  X : data/c
  y : (response-for/c X (or/c 0 1) #:classes? #t)
  predictors : (predictors-for/c X y #:classes? #t) = #f
  lambda : (or/c #f (and/c (listof (>=/c 0)) pair?)) = #f
  nlambda : exact-positive-integer? = 100
   lambda-min-ratio : (or/c #f (and/c real? (>=/c 0) (</c 1)))
= #f
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

The binomial path, as logistic-fit fits one point of it.

Examples:

> (glmnet-path-df (logistic-path X '(0 0 0 1 1 1) #:lambda '(0.3 0.1 0.03)))
'#(1 1 1)
> (glmnet-path-df (logistic-path cars+ "heavy" #:predictors '("mpg" "hp") #:nlambda 5))
'#(0 1 2 2 2)

procedure
(multinomial-path X
y
[ #:predictors predictors
#:lambda lambda
#:nlambda nlambda
#:lambda-min-ratio lambda-min-ratio
#:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters])
→ glmnet-path?
  X : data/c
  y : (response-for/c X (and/c integer? (>=/c 0)) #:classes? #t)
  predictors : (predictors-for/c X y #:classes? #t) = #f
  lambda : (or/c #f (and/c (listof (>=/c 0)) pair?)) = #f
  nlambda : exact-positive-integer? = 100
   lambda-min-ratio : (or/c #f (and/c real? (>=/c 0) (</c 1)))
= #f
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

The multinomial path, as multinomial-fit fits one point of it.

Examples:

> (define mpath (multinomial-path X '(0 0 1 1 2 2) #:lambda '(0.3 0.03)))
> (vector-ref (glmnet-path-coefficients mpath) 1)
'#(#(-1.2226648880844682 -1.2255649598724434 0.0)
   #(0.0 0.0 0.0)
   #(0.0 1.0608631342199921 0.1698597888820383))
> (glmnet-path-df (multinomial-path iris "Species" #:nlambda 5
                                    #:predictors '("Petal.Length" "Petal.Width")))
'#(0 2 2 2 2)

procedure
(cox-path X
y
[ statuses
#:predictors predictors
#:lambda lambda
#:nlambda nlambda
#:lambda-min-ratio lambda-min-ratio
#:alpha alpha
#:standardize? standardize?
#:thresh thresh
#:max-iters max-iters]) → glmnet-path?
  X : data/c
  y : (survival-for/c X)
  statuses : (statuses-for/c X y) = none
  predictors : (predictors-for/c X y) = #f
  lambda : (or/c #f (and/c (listof (>=/c 0)) pair?)) = #f
  nlambda : exact-positive-integer? = 100
   lambda-min-ratio : (or/c #f (and/c real? (>=/c 0) (</c 1)))
= #f
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

The Cox path, as cox-fit fits one point of it. There is no intercept, so glmnet-path-intercepts is #f.

Examples:

> (define cpath (cox-path X '(12.0 10.0 8.0 6.0 4.0 3.0) '(0 1 1 1 1 1)
#:lambda '(0.5 0.05)))
> (glmnet-path-coefficients cpath)
'#(#(0.353519335866768 0.0 0.0) #(2.336596711472855 0.0 0.0))
> (glmnet-path-df (cox-path patients '("months" "died") #:predictors '("age" "dose")
#:lambda '(0.5 0.05)))
'#(0 1)

procedure
(poisson-path X
y
[ #:predictors predictors
#:lambda lambda
#:nlambda nlambda
#:lambda-min-ratio lambda-min-ratio
#:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters])
→ glmnet-path?
  X : data/c
  y : (response-for/c X (>=/c 0))
  predictors : (predictors-for/c X y) = #f
  lambda : (or/c #f (and/c (listof (>=/c 0)) pair?)) = #f
  nlambda : exact-positive-integer? = 100
   lambda-min-ratio : (or/c #f (and/c real? (>=/c 0) (</c 1)))
= #f
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

The Poisson path, as poisson-fit fits one point of it.

Examples:

> (glmnet-path-df (poisson-path X '(1 2 2 3 5 8) #:lambda '(0.5 0.05)))
'#(1 2)
> (glmnet-path-df (poisson-path mtcars "carb" #:predictors '("hp" "wt") #:nlambda 5))
'#(0 1 2 2 2)

procedure
(mgaussian-path X
Y
[ #:predictors predictors
#:lambda lambda
#:nlambda nlambda
#:lambda-min-ratio lambda-min-ratio
#:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters])
→ glmnet-path?
  X : data/c
  Y : (responses-for/c X)
  predictors : (predictors-for/c X Y) = #f
  lambda : (or/c #f (and/c (listof (>=/c 0)) pair?)) = #f
  nlambda : exact-positive-integer? = 100
   lambda-min-ratio : (or/c #f (and/c real? (>=/c 0) (</c 1)))
= #f
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

The multi-response Gaussian path, as mgaussian-fit fits one point of it.

Examples:

> (define gpath (mgaussian-path X '((3.0 9.0) (5.0 8.0) (7.0 7.0)
                                    (9.0 6.0) (11.0 5.0) (13.0 4.0))
                                #:lambda '(1.0 0.1)))
> (glmnet-path-intercepts gpath)
'#(#(2.8330302779823358 9.083484861008833)
   #(1.1833030277982326 9.908348486100884))
> (glmnet-path-df (mgaussian-path mtcars '("mpg" "qsec") #:predictors '("wt" "hp") #:nlambda 5))
'#(0 2 2 2 2)

2.15 Cross-validation🔗ℹ

Every family has a cross-validation procedure, the equivalent of R’s cv.glmnet for that family, and they all return a glmnet-cv. Each takes its family’s data arguments and every keyword of its path fitter, which it passes on to each fit, and these:

#:type-measure is the loss, R’s type.measure. Each family offers R’s choices for it and defaults to R’s default, the first in the table below.
#:nfolds is the number of folds, at least 3 and at most the number of observations. The folds are drawn by random-fold-ids from current-pseudo-random-generator. It is ignored when #:fold-ids is given.
#:fold-ids, R’s foldid, assigns the observations to folds: one fold id per row of X, counting from 0, in a list, vector, flvector, f64vector, math/array array or Polars series, as a response can be. Every id from 0 to the largest must appear, and there must be at least 3 (see fold-ids/c).
#:grouped?, R’s grouped, computes the error and its standard error from the per-fold means when true, and from the per-observation losses otherwise. When the folds average fewer than 3 observations, they are never grouped; 'auc and 'C are always computed per fold; and when the folds average fewer than 10 observations, the Cox deviance is grouped. These adjustments, which R also makes, log a warning with the topic 'glmnet that names the procedure called.
#:lambda is as for the path fitter, but needs at least two values. Every fold’s path is fitted at those values. Without it, each fold’s path chooses its own sequence, as R’s does, and is evaluated at the full-data path’s values by interpolation.

The data are checked before any fold is fitted: the response must have what its family needs, and so must every fold’s training data (each class, or an event). When a fit fails all the same, the error names the cross-validation procedure and says which fit failed: the one to all the data, or the one to the training data of a given held-out fold.

Family	Procedure	#:type-measure
Gaussian	elnet-cv	'mse, 'deviance, 'mae
Binomial	logistic-cv	'deviance, 'class, 'auc, 'mse, 'mae
Multinomial	multinomial-cv	'deviance, 'class, 'mse, 'mae
Cox	cox-cv	'deviance, 'C
Poisson	poisson-cv	'deviance, 'mse, 'mae
Multi-response	mgaussian-cv	'mse, 'deviance, 'mae

Choosing λ by cross-validation describes the procedure and each measure. The examples in this section use 60 observations of 8 predictors, of which the first three carry the signal:

> (require glmnet/datasets)
> (random-seed 8)
> (define (noise) (- (* 2 (random)) 1))
> (define X60
    (for/list ([i (in-range 60)])
      (for/list ([j (in-range 8)])
        (noise))))
> (define beta '(3.0 -2.0 1.0 0.0 0.0 0.0 0.0 0.0))
> (define y60
    (for/list ([row (in-list X60)])
      (+ 1.0
         (for/sum ([b (in-list beta)] [x (in-list row)]) (* b x))
         (noise))))

struct
(struct glmnet-cv ( lambda
cvm
cvsd
cvup
cvlo
nzero
measure
name
path
lambda-min
lambda-1se
index-min
index-1se
fold-ids)
    #:transparent)
  lambda : (vectorof real?)
  cvm : (vectorof real?)
  cvsd : (vectorof real?)
  cvup : (vectorof real?)
  cvlo : (vectorof real?)
  nzero : (vectorof exact-nonnegative-integer?)
  measure : (or/c 'mse 'deviance 'mae 'class 'auc 'C)
  name : string?
  path : glmnet-path?
  lambda-min : real?
  lambda-1se : real?
  index-min : exact-nonnegative-integer?
  index-1se : exact-nonnegative-integer?
  fold-ids : (listof exact-nonnegative-integer?)

A cross-validated path, R’s cv.glmnet object. lambda holds the λ values of the full-data path, and cvm, cvsd, cvup, cvlo and nzero one entry for each:

cvm is the cross-validated error, cvsd its standard error, and cvup and cvlo are cvm plus and minus cvsd.
nzero counts the predictors in the model, as R counts them: the path’s glmnet-path-df, except for the multinomial, where it is the median over the classes rounded up, and the multi-response family, where R also counts the first response’s intercept.

A λ at which the standard error is undefined is left out, as R leaves it out; path still holds every fitted λ.

measure is the loss and name R’s name for it. lambda-min is the largest λ at which cvm is smallest, or largest for 'auc and 'C. lambda-1se is the largest λ whose cvm is within cvsd of that best value, with cvsd taken at lambda-min. index-min and index-1se are their positions in lambda, counting from 0. path is the path fitted to all the data, and fold-ids the fold of each observation.

A glmnet-cv implements gen:glmnet-model. Its path is path; predict and coef default to lambda-1se, as R’s predict.cv.glmnet does, and also accept 'lambda-min, 'lambda-1se or any λ; and deviance-ratio is the path’s at lambda-1se. For how it prints, see Printing.

Examples:

> (define cv (elnet-cv X60 y60))
> cv
#<glmnet-cv:gaussian
Measure: Mean-Squared Error
     Lambda Index Measure      SE Nonzero
min 0.05424    38  0.3984 0.05967       6
1se 0.16564    26  0.4468 0.06523       3>
> (glmnet-cv-lambda-min cv)
0.054239392702548954
> (vector-ref (glmnet-cv-cvm cv) (glmnet-cv-index-min cv))
0.3984109992356747
> (coef cv)
'#(0.878293049854064
   2.7178140193293583
   -1.4713240447178129
   0.6956206079817456
   0.0
   0.0
   0.0
   0.0
   0.0)
> (coef cv #:lambda 'lambda-min)
'#(0.9154747391997028
   2.903879277459048
   -1.7054265800660615
   0.8686835340984955
   -0.008767521015963693
   -0.11136295679101096
   0.0
   0.0
   -0.0343600088528011)
> (predict cv '((0.5 -0.5 0.0 0.0 0.0 0.0 0.0 0.0)))
'(2.9728620818776497)
> (deviance-ratio cv)
0.9109831280347133

procedure
(elnet-cv X
y
[ #:predictors predictors
#:type-measure type-measure
#:nfolds nfolds
#:fold-ids fold-ids
#:grouped? grouped?
#:lambda lambda
#:nlambda nlambda
#:lambda-min-ratio lambda-min-ratio
#:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters]) → glmnet-cv?
  X : data/c
  y : (response-for/c X real?)
  predictors : (predictors-for/c X y) = #f
  type-measure : (or/c 'mse 'deviance 'mae) = 'mse
  nfolds : (and/c exact-integer? (>=/c 3)) = 10
  fold-ids : fold-ids/c = #f
  grouped? : boolean? = #t
   lambda : (or/c #f (and/c (listof (>=/c 0)) (property/c length (>=/c 2))))
= #f
  nlambda : exact-positive-integer? = 100
   lambda-min-ratio : (or/c #f (and/c real? (>=/c 0) (</c 1)))
= #f
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Cross-validates elnet-path. 'mse and 'deviance are both the mean squared error, as in R; 'mae is the mean absolute error.

Examples:

> (elnet-cv X60 y60 #:type-measure 'mae #:alpha 0.5)
#<glmnet-cv:gaussian
Measure: Mean Absolute Error
     Lambda Index Measure      SE Nonzero
min 0.05656    45  0.5059 0.04876       6
1se 0.25060    29  0.5471 0.04654       3>
> (define car-cv
    (elnet-cv mtcars "mpg" #:predictors '("wt" "hp" "qsec")
              #:fold-ids (for/list ([i (in-range 32)]) (modulo i 4))))
> (coef car-cv)
'#(33.36590995019294 -3.150933800516765 -0.0213920284992272 0.0)
> (predict car-cv (list (cons "qsec" '(17.0)) (cons "hp" '(150)) (cons "wt" '(3.0))))
'(20.704304273758567)
> (define halves (for/list ([i (in-range 60)]) (modulo i 2)))
> (elnet-cv X60 y60 #:fold-ids halves)
elnet-cv: contract violation;
cross-validation needs at least 3 folds
  expected: fold ids from 0 to at least 2
  given: '(0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0
1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0
1 0 1 0 1)
  in: the #:fold-ids argument of
      (->*
       (data/c (response-for/c X real?))
       (#:predictors (predictors-for/c X y) ...)
       glmnet-cv?)
  contract from: <pkgs>/glmnet/core/elnet.rkt
  blaming: program
   (assuming the contract is correct)
  at: <pkgs>/glmnet/core/elnet.rkt:86:3

procedure
(logistic-cv X
y
[ #:predictors predictors
#:type-measure type-measure
#:nfolds nfolds
#:fold-ids fold-ids
#:grouped? grouped?
#:lambda lambda
#:nlambda nlambda
#:lambda-min-ratio lambda-min-ratio
#:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters]) → glmnet-cv?
  X : data/c
  y : (response-for/c X (or/c 0 1) #:classes? #t)
  predictors : (predictors-for/c X y #:classes? #t) = #f
   type-measure : (or/c 'deviance 'class 'auc 'mse 'mae)
= 'deviance
  nfolds : (and/c exact-integer? (>=/c 3)) = 10
  fold-ids : fold-ids/c = #f
  grouped? : boolean? = #t
   lambda : (or/c #f (and/c (listof (>=/c 0)) (property/c length (>=/c 2))))
= #f
  nlambda : exact-positive-integer? = 100
   lambda-min-ratio : (or/c #f (and/c real? (>=/c 0) (</c 1)))
= #f
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Cross-validates logistic-path. 'deviance is the binomial deviance, 'class the misclassification rate, 'auc the area under the ROC curve of each fold, and 'mse and 'mae the squared and absolute differences between the 0/1 labels of both classes and their predicted probabilities, summed over the two classes. When the folds average fewer than 10 observations, 'auc becomes 'deviance, as in R. y must hold both classes.

Examples:

> (define labels (for/list ([v (in-list y60)]) (if (> v 1.0) 1 0)))
> (logistic-cv X60 labels #:type-measure 'class)
#<glmnet-cv:binomial
Measure: Misclassification Error
     Lambda Index Measure      SE Nonzero
min 0.05351    21 0.05000 0.02546       4
1se 0.05872    20 0.06667 0.02722       4>
> (logistic-cv X60 labels #:type-measure 'auc #:nfolds 5)
#<glmnet-cv:binomial
Measure: AUC
     Lambda Index Measure      SE Nonzero
min 0.03360    26  0.9875 0.01250       4
1se 0.05872    20  0.9812 0.01875       4>
> (define heavy-cv
    (logistic-cv cars+ "heavy" #:predictors '("mpg" "hp")
                 #:fold-ids (for/list ([i (in-range 32)]) (modulo i 4))))
> (predict heavy-cv (hash "mpg" '(15.0 30.0) "hp" '(200 70)) #:type 'class)
'("yes" "no")

procedure
(multinomial-cv X
y
[ #:predictors predictors
#:type-measure type-measure
#:nfolds nfolds
#:fold-ids fold-ids
#:grouped? grouped?
#:lambda lambda
#:nlambda nlambda
#:lambda-min-ratio lambda-min-ratio
#:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters])
→ glmnet-cv?
  X : data/c
  y : (response-for/c X (and/c integer? (>=/c 0)) #:classes? #t)
  predictors : (predictors-for/c X y #:classes? #t) = #f
  type-measure : (or/c 'deviance 'class 'mse 'mae) = 'deviance
  nfolds : (and/c exact-integer? (>=/c 3)) = 10
  fold-ids : fold-ids/c = #f
  grouped? : boolean? = #t
   lambda : (or/c #f (and/c (listof (>=/c 0)) (property/c length (>=/c 2))))
= #f
  nlambda : exact-positive-integer? = 100
   lambda-min-ratio : (or/c #f (and/c real? (>=/c 0) (</c 1)))
= #f
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Cross-validates multinomial-path. The measures are those of logistic-cv, summed over the K classes, without 'auc. Every fold’s training data must contain every class.

Examples:

> (define classes
    (for/list ([v (in-list y60)])
      (cond [(< v -0.5) 0] [(< v 2.5) 1] [else 2])))
> (multinomial-cv X60 classes #:type-measure 'class)
#<glmnet-cv:multinomial
Measure: Misclassification Error
      Lambda Index Measure      SE Nonzero
min 0.009155    39  0.1333 0.04157       4
1se 0.015999    33  0.1667 0.04303       4>
> (multinomial-cv iris "Species" #:predictors '("Petal.Length" "Petal.Width")
                  #:fold-ids (for/list ([i (in-range 150)]) (modulo i 3)) #:type-measure 'class)
#<glmnet-cv:multinomial
Measure: Misclassification Error
     Lambda Index Measure      SE Nonzero
min 0.08946    18 0.03333 0.01764       1
1se 0.10775    16 0.04667 0.02404       1>

procedure
(cox-cv X
y
[ statuses
#:predictors predictors
#:type-measure type-measure
#:nfolds nfolds
#:fold-ids fold-ids
#:grouped? grouped?
#:lambda lambda
#:nlambda nlambda
#:lambda-min-ratio lambda-min-ratio
#:alpha alpha
#:standardize? standardize?
#:thresh thresh
#:max-iters max-iters]) → glmnet-cv?
  X : data/c
  y : (survival-for/c X)
  statuses : (statuses-for/c X y) = none
  predictors : (predictors-for/c X y) = #f
  type-measure : (or/c 'deviance 'C) = 'deviance
  nfolds : (and/c exact-integer? (>=/c 3)) = 10
  fold-ids : fold-ids/c = #f
  grouped? : boolean? = #t
   lambda : (or/c #f (and/c (listof (>=/c 0)) (property/c length (>=/c 2))))
= #f
  nlambda : exact-positive-integer? = 100
   lambda-min-ratio : (or/c #f (and/c real? (>=/c 0) (</c 1)))
= #f
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Cross-validates cox-path. 'deviance is the partial likelihood deviance per observation: when grouped, each fold contributes the deviance of all the data less that of its training data, at the fold’s coefficients, as in R; otherwise the deviance of the fold itself. 'C is Harrell’s concordance index of each fold. Every fold’s training data must contain an event.

A held-out fold’s own deviance is undefined when the fold has no event, or when its first event is among its last two observations in time order. R stops then, and so does cox-cv, naming the fold. With #:grouped? #t, the default, the fold’s own deviance is not needed.

Examples:

> (define times (for/list ([v (in-list y60)]) (exp (* -0.3 v))))
> (define statuses
    (for/list ([i (in-range 60)])
      (if (zero? (modulo i 5)) 0 1)))
> (cox-cv X60 times statuses)
#<glmnet-cv:cox
Measure: Partial Likelihood Deviance
     Lambda Index Measure     SE Nonzero
min 0.02501    35   3.955 0.2004       7
1se 0.07637    23   4.137 0.1787       4>
> (cox-cv X60 times statuses #:type-measure 'C)
#<glmnet-cv:cox
Measure: C-index
    Lambda Index Measure      SE Nonzero
min 0.1764    14    0.95 0.01859       3
1se 0.1764    14    0.95 0.01859       3>
> (define survival60 (hash "time" times "status" statuses
                           "x1" (map car X60) "x2" (map cadr X60)))
> (cox-cv survival60 '("time" "status") #:predictors '("x1" "x2"))
#<glmnet-cv:cox
Measure: Partial Likelihood Deviance
     Lambda Index Measure     SE Nonzero
min 0.00986    45   4.789 0.3301       2
1se 0.16075    15   5.109 0.3501       2>
> (define thirds (for/list ([i (in-range 60)]) (modulo i 3)))
> (define fold-0-censored
    (for/list ([i (in-range 60)])
      (if (zero? (modulo i 3)) 0 1)))
> (cox-cv X60 times fold-0-censored #:fold-ids thirds #:grouped? #f)
cox-cv: a held-out fold has no event, so its deviance is
undefined without grouping; use #:grouped? #t
  held-out fold: 0

procedure
(poisson-cv X
y
[ #:predictors predictors
#:type-measure type-measure
#:nfolds nfolds
#:fold-ids fold-ids
#:grouped? grouped?
#:lambda lambda
#:nlambda nlambda
#:lambda-min-ratio lambda-min-ratio
#:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters]) → glmnet-cv?
  X : data/c
  y : (response-for/c X (>=/c 0))
  predictors : (predictors-for/c X y) = #f
  type-measure : (or/c 'deviance 'mse 'mae) = 'deviance
  nfolds : (and/c exact-integer? (>=/c 3)) = 10
  fold-ids : fold-ids/c = #f
  grouped? : boolean? = #t
   lambda : (or/c #f (and/c (listof (>=/c 0)) (property/c length (>=/c 2))))
= #f
  nlambda : exact-positive-integer? = 100
   lambda-min-ratio : (or/c #f (and/c real? (>=/c 0) (</c 1)))
= #f
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Cross-validates poisson-path. 'deviance is the Poisson deviance; 'mse and 'mae compare the counts with the predicted means.

Examples:

> (define counts
    (for/list ([v (in-list y60)])
      (inexact->exact (round (exp (* 0.3 v))))))
> (poisson-cv X60 counts)
#<glmnet-cv:poisson
Measure: Poisson Deviance
     Lambda Index Measure      SE Nonzero
min 0.02356    37  0.1920 0.03408       5
1se 0.09512    22  0.2242 0.04454       5>
> (poisson-cv (hash "count" counts "x1" (map car X60) "x2" (map cadr X60)) "count"
              #:predictors '("x1" "x2"))
#<glmnet-cv:poisson
Measure: Poisson Deviance
     Lambda Index Measure      SE Nonzero
min 0.00442    55  0.2375 0.05644       2
1se 0.15146    17  0.2868 0.07922       2>

procedure
(mgaussian-cv X
Y
[ #:predictors predictors
#:type-measure type-measure
#:nfolds nfolds
#:fold-ids fold-ids
#:grouped? grouped?
#:lambda lambda
#:nlambda nlambda
#:lambda-min-ratio lambda-min-ratio
#:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters]) → glmnet-cv?
  X : data/c
  Y : (responses-for/c X)
  predictors : (predictors-for/c X Y) = #f
  type-measure : (or/c 'mse 'deviance 'mae) = 'mse
  nfolds : (and/c exact-integer? (>=/c 3)) = 10
  fold-ids : fold-ids/c = #f
  grouped? : boolean? = #t
   lambda : (or/c #f (and/c (listof (>=/c 0)) (property/c length (>=/c 2))))
= #f
  nlambda : exact-positive-integer? = 100
   lambda-min-ratio : (or/c #f (and/c real? (>=/c 0) (</c 1)))
= #f
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = #t
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Cross-validates mgaussian-path. The measures are those of elnet-cv, summed over the responses.

Examples:

> (define Y60
    (for/list ([row (in-list X60)] [v (in-list y60)])
      (list v (- (list-ref row 1) (list-ref row 3)))))
> (mgaussian-cv X60 Y60)
#<glmnet-cv:mgaussian
Measure: Mean-Squared Error
     Lambda Index Measure      SE Nonzero
min 0.03410    43  0.3820 0.03356       7
1se 0.09488    32  0.4129 0.03545       6>
> (mgaussian-cv mtcars '("mpg" "qsec") #:predictors '("wt" "hp")
                #:fold-ids (for/list ([i (in-range 32)]) (modulo i 4)))
#<glmnet-cv:mgaussian
Measure: Mean-Squared Error
    Lambda Index Measure    SE Nonzero
min 0.1370    40   9.749 1.207       3
1se 0.8803    20  10.786 1.720       3>

procedure
(random-fold-ids n [#:nfolds nfolds])
→ (listof exact-nonnegative-integer?)
n : exact-positive-integer?
nfolds : exact-positive-integer? = 10

Assigns n observations to nfolds folds at random, as R’s sample(rep(seq(nfolds), length = n)) does: the fold ids 0, 1, ..., (- nfolds 1), 0, ... are shuffled with current-pseudo-random-generator, so that the folds differ in size by at most one. nfolds, given or by default, must not exceed n. The cross-validation procedures call it when they are not given #:fold-ids; calling it directly gives folds to reuse across calls.

Examples:

> (random-fold-ids 10 #:nfolds 3)
'(0 0 2 2 0 0 1 2 1 1)
> (define (draw)
    (parameterize ([current-pseudo-random-generator
                    (make-pseudo-random-generator)])
      (random-seed 1)
      (random-fold-ids 10 #:nfolds 3)))
> (equal? (draw) (draw))
#t
> (random-fold-ids 3 #:nfolds 5)
random-fold-ids: contract violation;
there are more folds than observations
folds: 5
observations: 3
  in: (->i
       ((n exact-positive-integer?))
       (#:nfolds (nfolds exact-positive-integer?))
       #:pre/desc
       (n nfolds)
       (folds-within n nfolds)
       (_ (listof natural?)))
  contract from: <pkgs>/glmnet/core/cv.rkt
  blaming: program
   (assuming the contract is correct)
  at: <pkgs>/glmnet/core/cv.rkt:31:3

value
fold-ids/c : flat-contract?

The contract on the #:fold-ids argument of every cross-validation procedure. It accepts #f, for folds drawn by random-fold-ids, or fold ids: a non-empty list, vector, flvector, f64vector, math/array array or Polars series of non-negative integers, exact or, as in an flvector, inexact, that use every fold from 0 to the largest id, of which there are at least 3. A violation says which fold is missing. The procedures check the ids again on their own copy, with one id per observation.

Examples:

> (require racket/flonum)
> (contract-first-order-passes? fold-ids/c '(0 1 2 0 1 2))
#t
> (contract-first-order-passes? fold-ids/c (flvector 0.0 1.0 2.0 2.0))
#t
> (contract-first-order-passes? fold-ids/c #f)
#t
> (contract-first-order-passes? fold-ids/c '(0 1 0 1))
#f
> (contract-first-order-passes? fold-ids/c (vector 0 2 3 0 2 3))
#f
> (elnet-cv X60 y60 #:fold-ids (for/vector ([i (in-range 60)]) (modulo i 4)))
#<glmnet-cv:gaussian
Measure: Mean-Squared Error
     Lambda Index Measure      SE Nonzero
min 0.04942    39  0.4160 0.04962       6
1se 0.13752    28  0.4639 0.11939       3>
> (elnet-cv X60 y60 #:fold-ids (for/list ([i (in-range 60)]) (* 2 (modulo i 3))))
elnet-cv: contract violation;
a fold has no observations; fold ids must cover 0 to 4
  expected: an observation in fold 1
  given: '(0 2 4 0 2 4 0 2 4 0 2 4 0 2 4 0 2 4 0 2 4 0 2 4 0
2 4 0 2 4 0 2 4 0 2 4 0 2 4 0 2 4 0 2 4 0 2 4 0 2 4 0 2 4 0
2 4 0 2 4)
  in: the #:fold-ids argument of
      (->*
       (data/c (response-for/c X real?))
       (#:predictors (predictors-for/c X y) ...)
       glmnet-cv?)
  contract from: <pkgs>/glmnet/core/elnet.rkt
  blaming: program
   (assuming the contract is correct)
  at: <pkgs>/glmnet/core/elnet.rkt:86:3

2.16 Formulas🔗ℹ

The formula front end fits any family from named data: a table (see Tables) or a Polars dataframe. A formula names the response and, in R’s formula algebra, the predictor terms. formula-fit, formula-path and formula-cv expand the terms against the data’s columns, as R’s terms does, build their design matrix, as R’s model.matrix does, and call the fit procedure, path fitter or cross-validation procedure of the family that #:family names on it. They return a formula-model, which keeps the formula, the names of the design matrix’s columns and the expanded terms, so that coef keys the coefficients by name and predict builds the design matrix of new named data (see Generic model interface). Formulas and named data works through examples, The formula algebra explains the algebra, Transforms the transforms, and Categorical predictors the factors.

A dataframe is read as (polars->table df) would be, and the results are the same, except that only the columns the formula uses are converted: those its terms read and, for a fit, the response columns. The other columns may have any dtype, and missing values. A converted column needs a numeric, boolean, string, categorical or enum dtype and no missing value; a response needs a numeric one, except the class labels of a binomial or multinomial response and a Cox status, which may be boolean. An error names the column. A dataframe with no rows is an error only for a formula that reads a column of it, as a table is.

The terms of a formula expand as R’s terms expands them:

A column name is a term of one variable, that column. all is a term for each column of the table that is not a response column, in the table’s order, as R’s . is.
A transform, such as (log hp) or (I (expt hp 2)), is a term of one variable, computed from columns (see below).
(factor x), R’s factor(x), is a term of one variable, the values of the column x or of the transform x as a factor (see below).
(+ a b), or a + b, is the terms of a, then those of b. Terms written side by side after the response are joined in the same way.
(- a b), or a - b, is the terms of a except those equal to a term of b. A term of b that a does not have is ignored. (- a) removes a from nothing.
(: a b), or a : b, is every term of a combined with every term of b: an interaction, whose variables are those of both.
(* a b), or a * b, crosses them: the terms of a + b + a : b. When a has no terms, as 1 and 0 have none, neither has a * b, as in R, whose y ~ 0*x + z is y ~ z - 1.
(^ a n), or a ^ n, crosses a with itself: every interaction of at most n of the terms of a, for an exact integer n of at least 2. A variable crossed with itself is itself, so (^ x 2) is x, as x^2 is in R.
1 keeps the intercept and 0 removes it, so - 1 removes it too. Inside the removed operand of - their meanings swap, and the last one written wins, as in R. A formula without them has an intercept.

A term is a set of variables, so (: wt hp) and (: hp wt) are the same term. Each operation drops the terms it repeats, keeping the first. The terms are then ordered by degree, the main effects first and then the interactions of two variables, of three, and so on, each degree in the order the terms first appear; the variables of a term are in the order they first appear in the formula. The prefix forms with more operands are the infix forms folded from the left: (* a b c) is a * b * c.

The design matrix, which formula-design-matrix returns, has one column per term for numeric variables: a column of the table, or for an interaction the product of its variables’ columns, named by joining their names with colons, as R names them: "wt:hp". A factor has a column for each of its levels, or for each but the first (see below), and an interaction a column for each combination of its variables’ columns, the first variable’s varying fastest. A column of the table keeps its name, where R puts backticks around a name that R’s syntax does not allow, such as "blood pressure". It has no intercept column, since the family’s procedure fits the intercept. Every column the formula names, even one that it removes, must be a column of the table, and so must the response columns, which must be distinct. Names are compared as strings. The design matrix’s column names must be distinct, and none can be "(Intercept)", since coef keys the coefficients by them and the intercept by "(Intercept)"; the formula procedures raise an error that names the column otherwise.

A group that starts with an identifier other than the operators, such as (log hp), is a transform, as R’s log(hp) is: a Racket expression, evaluated for each row of the table, whose values are a column of the design matrix named by the transform’s source, "(log hp)". (I expr), R’s I(), is the transform whose expression is expr. Inside a transform the operators are Racket’s: (I (* wt hp)) is the product of two columns, and (log (+ hp 1)) adds 1. An identifier in argument position, that is, not first in a group, is the table’s column of that name when the table has one, and otherwise the Racket binding of that name where the formula is written, as R looks for a name in the data and then in the formula’s environment. An identifier first in a group is always the Racket binding, even when the table has a column of that name, as R looks up the function of a call by name and skips a column: with a column max, (max max x) is the larger of that column and x, R’s pmax(max, x). A name that the transform binds itself, with let, lambda or a for form, is its own, a name in quoted data is data, and a name that Racket’s forms match as a literal, =>, else, unquote, unquote-splicing, ... or _, keeps its Racket meaning; the columns a transform reads are the others. A column named like one of these literals cannot be read inside a transform, where (log else) is Racket’s syntax error else: not allowed as an expression; write it as an ordinary term, or rename it in the table. The expression is evaluated once for each row, with each column name standing for the row’s value, so a transform is elementwise. A fit evaluates each transform the terms use once on the table, as R’s model.frame does, and takes a factor’s levels and the design matrix from those values, so a transform with side effects or random values gives both from the same draw. A transform that - removes is not evaluated, where R’s model.frame still evaluates it once. A column of numbers gives its value as a flonum, and a column of strings, symbols or booleans gives the value itself, as R’s calls read a character or logical column, so (equal? Species "setosa") is R’s I(Species == "setosa") and (not b) is R’s I(!b). A column that a transform reads must hold one kind of value, numbers, strings, symbols or booleans, and its numbers must be finite; an error names the transform and the column. Strings and symbols are two kinds here, though a factor’s levels match them by label, since a transform can tell them apart: (equal? g "a") is false for the symbol 'a. predict needs each such column to hold the kind of value it held when the model was fitted, and an error names the transform, the column and both kinds; a boolean column given as 1 and 0 would otherwise change (if b x 0) silently, as 0 is true in Racket. A name that is neither a column nor bound is an error, naming it, when the transform is evaluated, not when the formula is compiled. Each value must be a real number and finite, or else each a string, a symbol or a boolean, which makes the transform a factor (see below), and an error names the transform and the row. A transform must read at least one column. It is a variable of the algebra, so (* (log hp) wt) has the terms "(log hp)", "wt" and "(log hp):wt", and a transform written twice, as the same datum, is one term.

A variable is a factor, a categorical variable, when its values, a column’s or a transform’s, are strings or symbols, or booleans, as R’s character and logical variables are, and under (factor x), whose values may be numbers too. Otherwise its values must be numbers. A factor’s levels are its distinct values, labelled as R labels them: a string itself, a symbol’s name, "FALSE" and "TRUE" for booleans, and a number as Racket prints it, without a trailing .0; values with the same label are one level. They are sorted as R’s factor() sorts them: numbers by value, labels by string<?, which is R’s order in the C locale, and "FALSE" before "TRUE". A boolean variable other than (factor x) has both boolean levels, even when one is absent, as R’s logical variable has. A factor needs at least two levels; a column or a transform whose values mix numbers, strings or symbols, and booleans is an error that names it. A factor is coded by treatment contrasts, as R’s model.matrix codes it by default: a 0/1 column for each level but the first, the baseline, named by the variable’s name and the level’s label, as "(factor cyl)6" or "Speciesversicolor". It has a column for every level instead, dummies, where R’s model.matrix has: in a term that has other variables, when no earlier term contains all of them (R’s factors attribute of terms), and, without an intercept, for the first factor of the first term that has one. So in (~ mpg wt : (factor cyl)) the factor has dummies, and after wt, or after wt : hp, which contains wt, it has contrasts. The fitted model keeps the levels (see formula-model-levels), and predict codes a new table with them; a value whose level the model was not fitted with is an error that names the factor and the new levels.

A response column that stands alone as a term on the right-hand side is dropped from it, and a warning naming the procedure called is logged on the 'glmnet topic, as R’s model.matrix warns. An interaction with a response column is kept, as in R. The columns of a (surv time status) or multi-column response are each treated in the same way.

The intercept of the fit is the formula’s: without #:intercept?, the fit procedures fit an intercept unless the formula has 0 or - 1. An explicit #:intercept? must agree with a formula that writes 1, 0 or - 1, which its contract checks, naming both; with a formula that writes none, it decides. The Cox family fits no intercept, and accepts 1, 0 and - 1 with any #:intercept?. As in R, they still decide how a factor is coded: with 0 or - 1, the first factor has a column for every level (see above). A formula whose terms leave no predictors, such as (~ y 1), cannot be fitted: glmnet needs at least one predictor.

The examples in this section use R’s mtcars, 32 cars of the 1974 Motor Trend road tests, and R’s iris, 150 irises of three species, which glmnet/datasets provides as tables (see Example datasets):

> (require glmnet/data/polars
glmnet/datasets)
> (table-column-names mtcars)
'("mpg" "cyl" "disp" "hp" "drat" "wt" "qsec" "vs" "am" "gear" "carb")
> (table-column-names iris)
'("Sepal.Length" "Sepal.Width" "Petal.Length" "Petal.Width" "Species")

Some also use mtcars as a dataframe, from the datasets package, with a text column of the cars’ names:

> (require (only-in datasets load-dataset)
(only-in polars column-names)
(prefix-in pl: (only-in polars head)))
> (define cars (load-dataset 'mtcars #:format 'polars))
> (column-names cars)
'("model" "mpg" "cyl" "disp" "hp" "drat" "wt" "qsec" "vs" "am" "gear" "carb")

syntax
(~ response term ...)
(~ response maybe-sign term operation ...)

response = column
| (surv time-column status-column)
| (column ...+)

term = column
| all
| 1
| 0
| (+ term ...+)
| (- term ...+)
| (* term term ...+)
| (: term term ...+)
| (^ term power)
| (maybe-sign term operation ...+)
| (I expr)
| (proc-id arg-expr ...)
| (factor column)
| (factor (I expr))
| (factor (proc-id arg-expr ...))

operation = + term
| - term
| * term
| : term
| ^ power

maybe-sign =
| +
| -

column = identifier
| string

A formula: the response, then the right-hand side, either terms side by side, which are joined as by +, or terms with infix operators between them. The infix operators have R’s precedence: ^ binds tightest, then a leading sign, then :, then *, then + and -; each groups from the left, except that a power cannot be raised again, which R does not allow either. A parenthesized group is a prefix form when it starts with an operator and has no operators between its terms, a factor when it starts with factor, a transform when it starts with I or another identifier that is not a word of the formula language, and an infix one otherwise. A power is an exact integer of at least 2. The Racket reader’s infix dots make (y . ~ . x + z) the same as (~ y x + z), so a formula can read as R writes it.

The body is quoted, as by quote, except for its transforms, and the result is (make-formula 'response rhs ...), with the elements of the right-hand side as written. Each transform becomes a transform-term? value that computes it, whose name is its source, the datum as write writes it with print-reader-abbreviations on, so that quoted data is written 'x and not (quote x). A transform’s proc-id must be bound where the formula is written: in a module, anywhere in it; at the top level, as in the REPL, by a definition evaluated before the formula, since a later one cannot be seen there. A name in argument position is read when the transform runs, so at the top level it can be defined after the formula. An arg-expr or the expr of I is any Racket expression, checked as it is expanded, where the names bound in it are known: ^, R’s power, is a syntax error that says to write expt unless it is bound, and so is R’s infix arithmetic, such as (hp * wt), whose first name is not bound, which says to write (* hp wt). A column is written as an identifier or a string, and as a string when its name is a word of the formula language (all, surv, the operators, and R’s / and %in%, which it does not have), starts with -, or contains :, *, ^, / or +. The reader reads wt:hp and -wt as one name, so an operator needs spaces around it; written as an identifier, such a name is a syntax error that says so. So is a number other than 0 and 1; a 0 or 1 written with more than its digit, such as -0 or +0, since the reader reads both as 0 and drops the sign that R reads as an operator, so that R’s -0 is written (- 0) and its +0 (+ 0); a group that is neither a prefix form, an infix form nor a transform, such as (1 x z); a quoted name, such as 'hp, since ~ quotes the names itself; and R’s / or %in%, between terms or at the head of a group, where the error for / says to write a ratio as (I (/ hp wt)). The error points at the form that is wrong. Inside a transform, a column whose name is not an identifier is written with bars, as (log |blood pressure|).

Whether a 0 or 1 is written with more than its digit is read from its source location, the only trace of its spelling. A macro that builds one into a formula therefore gives it a location of its own, or none: a 0 made by datum->syntax with the location of a longer form, such as the #f option it stands for, counts as written with more than its digit, and is a syntax error.

(factor column) is R’s factor(column), and is quoted as the list (factor column). factor of a transform is the list of 'factor and the transform’s transform-term? value. A factor group takes one column or transform, and is named by its source, as "(factor cyl)"; a column whose name is not an identifier is written there as a string, "(factor \"n k\")".

The response is one column, (surv time-column status-column) for the Cox family, or a list of columns for the multi-response Gaussian family. It is not a transform: a response that starts with I, or with a bound name and holds more than column names, such as (log (+ mpg 1)), is a syntax error that says a transformed response is not supported. So is a list of columns whose first name is a procedure where the formula is written, such as (log mpg), an error raised when the formula is made, as only then is the value known; the columns of such a response are written as strings, as in ("log" "mpg").

Examples:

> (~ mpg (* wt hp))
(~ mpg (* wt hp))
> (mpg . ~ . wt * hp)
(~ mpg wt * hp)
> (formula-predictor-names (mpg . ~ . wt * hp) mtcars)
'("wt" "hp" "wt:hp")
> (formula-predictor-names (~ mpg (^ (+ wt hp qsec) 2)) mtcars)
'("wt" "hp" "qsec" "wt:hp" "wt:qsec" "hp:qsec")
> (formula-predictor-names (mpg . ~ . (wt + hp + qsec) ^ 2 - wt : hp) mtcars)
'("wt" "hp" "qsec" "wt:qsec" "hp:qsec")
> (formula-predictor-names (mpg . ~ . 0 + wt + hp) mtcars)
'("wt" "hp")
> (formula-predictor-names (~ mpg (- all cyl disp)) mtcars)
'("hp" "drat" "wt" "qsec" "vs" "am" "gear" "carb")
> (formula-predictor-names (mpg . ~ . (log hp) * wt + (I (/ disp cyl))) mtcars)
'("(log hp)" "wt" "(I (/ disp cyl))" "(log hp):wt")
> (formula-predictor-names (mpg . ~ . wt * (factor cyl)) mtcars)
'("wt" "(factor cyl)6" "(factor cyl)8" "wt:(factor cyl)6" "wt:(factor cyl)8")
> (formula-predictor-names (mpg . ~ . (factor (> gear 3)) + wt) mtcars)
'("(factor (> gear 3))TRUE" "wt")
> (formula-predictor-names (Sepal.Length . ~ . 0 + Species + Petal.Width) iris)
'("Speciessetosa" "Speciesversicolor" "Speciesvirginica" "Petal.Width")
> (formula-predictor-names (Sepal.Length . ~ . (equal? Species "setosa") + Petal.Width) iris)
'("(equal? Species \"setosa\")TRUE" "Petal.Width")
> (~ (surv time status) age "blood pressure")
(~ (surv time status) age "blood pressure")
> (~ mpg wt:hp)
eval:347:0: ~: wt:hp reads as one name; put spaces around an
operator, as in wt : hp, or write a column with this name as
a string, "wt:hp"
  at: wt:hp
  in: (~ mpg wt:hp)
  parsing context:
   while parsing a column name
    term: wt:hp
    location: eval:347:0
   while parsing a term: a column, all, 1, 0, a transform
such as (log x), (factor x), or a group such as (* x z) or
(x + z)
    term: wt:hp
    location: eval:347:0
   while parsing the right-hand side of a formula
    term: (wt:hp)
    location: eval:347:0

value
formula-term/c : flat-contract?

Accepts a term as data, as ~ makes it: a column name (a string, or a symbol that ~ accepts as a column name), 'all, 0, 1, a transform-term? value, a list of 'factor and a column name or a transform-term? value, a prefix form, or a group of terms with infix operators between them. A transform is a transform-term? value, not a list, which would be a group of terms.

Examples:

> (formula-term/c '(* wt hp))
#t
> (formula-term/c '(wt + hp))
#t
> (formula-term/c '(^ (+ wt hp) 2))
#t
> (formula-term/c (transform-term "(log wt)" '(wt) log))
#t
> (formula-term/c '(factor cyl))
#t
> (formula-term/c '(log wt))
#f

value
formula-rhs/c : flat-contract?

Accepts the right-hand side of a formula as data, as ~ takes it: a list of terms, joined as by +, or an infix sequence, a term with a leading sign or with infix operators and terms after it. The empty list is the right-hand side of a formula without predictors.

Examples:

> (formula-rhs/c '(wt hp (: wt hp)))
#t
> (formula-rhs/c '(- 1 + wt * hp))
#t
> (formula-rhs/c '(wt hp + qsec))
#f

value
formula-response/c : flat-contract?

Accepts a response as data: a column name, a list of 'surv and two column names, or a non-empty list of column names.

Examples:

> (formula-response/c '(surv time status))
#t
> (formula-response/c '(surv time))
#f

procedure
(transform-term name columns proc) → transform-term?
  name : string?
  columns : (and/c (listof (or/c string? symbol?)) pair?)
  proc : (procedure-arity-includes/c (length columns))

A transform as data, for make-formula: the design-matrix column name, whose value in each row is proc applied to the row’s value of each of the columns, in order: a flonum for a column of numbers, and the value itself for a column of strings, symbols or booleans. Each of the columns must be a column of the table that holds one kind of value, strings and symbols counting as two, and whose numbers are finite; new data for predict must give it the same kind. ~ makes the same value from a transform written in a formula, with its source as the name and the names it reads as the columns, except that a name of that transform that is not a column of the table is the Racket binding of that name.

A procedure has no source and names no columns, so a transform as data names both. Two transforms are equal? when their names and columns are, so a transform named by its source is equal? to the one that ~ makes from that source. It prints as #<transform-term and its name, and a formula prints it as its name.

Examples:

> (define log-hp (transform-term "(log hp)" '(hp) log))
> (define f (make-formula 'mpg log-hp '* 'wt))
> f
(~ mpg (log hp) * wt)
> (equal? f (mpg . ~ . (log hp) * wt))
#t
> (define power-to-weight (transform-term "hp/wt" '("hp" "wt") /))
> (define P (formula-design-matrix (make-formula 'mpg power-to-weight) mtcars))
> (design-matrix->rows (design-matrix-select-rows P '(0 1 2)))
'((41.98473282442748) (38.26086956521739) (40.08620689655173))

procedure
(transform-term? v) → boolean?
v : any/c

Returns #t if v is a transform, as transform-term and ~ make them.

Examples:

> (formula-terms (~ mpg (log hp) wt))
'(#<transform-term (log hp)> wt)
> (transform-term? (car (formula-terms (~ mpg (log hp) wt))))
#t

procedure
(make-formula response rhs ...) → formula?
response : formula-response/c
rhs : any/c

The formula with response and right-hand side rhss, which is what ~ expands to. The list of the rhss must satisfy formula-rhs/c. It builds a formula from names or terms computed at run time; a transform in it is a transform-term.

Examples:

> (define chosen '("wt" "hp" "qsec"))
> (apply make-formula "mpg" chosen)
(~ "mpg" "wt" "hp" "qsec")
> (make-formula 'mpg `(^ (+ ,@chosen) 2))
(~ mpg (^ (+ "wt" "hp" "qsec") 2))
> (make-formula 'mpg 'wt '* 'hp)
(~ mpg wt * hp)
> (equal? (make-formula 'mpg 'wt '* 'hp) (mpg . ~ . wt * hp))
#t
> (make-formula 'mpg 'wt (list 'factor "cyl"))
(~ mpg wt (factor "cyl"))

procedure
(formula? v) → boolean?
v : any/c

Returns #t if v is a formula. Two formulas are equal? when their responses and right-hand sides are, as written, so (~ mpg (* wt hp)) and (~ mpg wt * hp) are different formulas with the same terms, and two transforms are equal when they are written the same. A formula prints as the ~ form that makes it.

Examples:

> (formula? (~ mpg all))
#t
> (formula? '(~ mpg all))
#f
> (equal? (~ mpg wt * hp) (mpg . ~ . wt * hp))
#t

procedure
(formula-response f) → formula-response/c
f : formula?
procedure
(formula-terms f) → formula-rhs/c
f : formula?

The response and the right-hand side of f, as written: its terms, and the infix operators between them.

Examples:

> (formula-response (~ (surv time status) age))
'(surv time status)
> (formula-terms (mpg . ~ . 1 + wt * hp))
'(1 + wt * hp)
> (formula-terms (~ mpg wt (- all cyl)))
'(wt (- all cyl))

procedure
(formula-predictor-names f data) → (listof string?)
f : formula?
data : (or/c table? named-data?)

The names of the columns of f’s design matrix on data, a table or a dataframe, which are the names of the model’s coefficients, in their order, as R’s colnames(model.matrix(f, data)) without (Intercept). It is empty for a formula without predictors. It reads the values of the columns the terms use, which decide a factor’s levels, and evaluates the transforms, as R’s model.matrix does.

Examples:

> (formula-predictor-names (~ mpg wt hp (: wt hp qsec)) mtcars)
'("wt" "hp" "wt:hp:qsec")
> (formula-predictor-names (mpg . ~ . wt * hp * qsec - wt : hp : qsec) mtcars)
'("wt" "hp" "qsec" "wt:hp" "wt:qsec" "hp:qsec")
> (formula-predictor-names (~ mpg (: all wt)) mtcars)
'("wt"
  "cyl:wt"
  "disp:wt"
  "hp:wt"
  "drat:wt"
  "wt:qsec"
  "wt:vs"
  "wt:am"
  "wt:gear"
  "wt:carb")
> (formula-predictor-names (mpg . ~ . (factor cyl) * (factor am)) mtcars)
'("(factor cyl)6"
  "(factor cyl)8"
  "(factor am)1"
  "(factor cyl)6:(factor am)1"
  "(factor cyl)8:(factor am)1")
> (formula-predictor-names (~ mpg 1) mtcars)
'()
> (formula-predictor-names (~ mpg (- all model)) cars)
'("cyl" "disp" "hp" "drat" "wt" "qsec" "vs" "am" "gear" "carb")

procedure
(formula-design-matrix f data) → design-matrix?
f : formula?
data : (or/c table? named-data?)

The design matrix of f on data, a table or a dataframe, with one named column per predictor, which is what the formula procedures fit: R’s model.matrix(f, data) without its (Intercept) column. The formula must have at least one predictor. The name is not formula-model-matrix, which would read as an accessor of a formula-model.

Examples:

> (define X (formula-design-matrix (~ mpg (* wt hp)) mtcars))
> X
#<design-matrix 32x3>
> (design-matrix-column-names X)
'("wt" "hp" "wt:hp")
> (design-matrix->rows (design-matrix-select-rows X '(0 1 2)))
'((2.62 110.0 288.2) (2.875 110.0 316.25) (2.32 93.0 215.76))
> (define L (formula-design-matrix (~ mpg hp (log hp) (I (expt hp 2))) mtcars))
> (design-matrix->rows (design-matrix-select-rows L '(0 1 2)))
'((110.0 4.700480365792417 12100.0)
(110.0 4.700480365792417 12100.0)
(93.0 4.532599493153256 8649.0))
> (define F (formula-design-matrix (~ mpg wt (factor cyl)) mtcars))
> (design-matrix-column-names F)
'("wt" "(factor cyl)6" "(factor cyl)8")
> (design-matrix->rows (design-matrix-select-rows F '(0 1 2)))
'((2.62 1.0 0.0) (2.875 1.0 0.0) (2.32 0.0 0.0))

struct
(struct formula-model (formula predictor-names fit)
    #:transparent)
  formula : formula?
  predictor-names : (listof string?)
  fit : glmnet-model?

A model fitted from a formula. fit is the result of the family’s procedure: a single fit, a glmnet-path or a glmnet-cv. predictor-names names its predictors, the columns of the design matrix, in the order of its coefficients. Only formula-fit, formula-path and formula-cv make a formula model, since only they know that its names are those of the columns its fit was fitted to; the constructor is not exported. The model also keeps the terms it was fitted with, expanded, with its factors’ levels (see formula-model-levels), and for a binomial or multinomial response of strings, symbols or booleans, its classes; these are internal.

A formula model implements gen:glmnet-model through fit: predict, coef and deviance-ratio give what they give for fit, except that coef keys the coefficients by name and predict takes a table or a dataframe, from whose columns it builds the design matrix of the fitted terms, reading only those the terms read. It does not expand the formula again, so all stands for the columns it stood for in the fit, and the new data’s columns can come in any order, without the response. It evaluates the transforms again, on the new rows: each name of a transform that was a column in the fit must be a column of the new data, and one that was a Racket binding is read again. It codes the factors with the fit’s levels, whichever of them the new rows have, and a level that the fit did not have is an error that names the factor and the new levels. For a response with classes, coef keys a multinomial model’s coefficients by class, and predict with #:type 'class returns classes, as R’s glmnet does for a factor response. glmnet-model-predictor-names returns predictor-names, and glmnet-model-response-names the formula’s response columns. A formula model prints as fit does, with the formula after the family.

Examples:

> (define m (formula-fit (mpg . ~ . wt * hp) mtcars #:lambda 0.1))
> m
#<glmnet:gaussian (~ mpg wt * hp) λ=0.1 dev=0.8321 nz=3/3>
> (formula-model-predictor-names m)
'("wt" "hp" "wt:hp")
> (formula-model-fit m)
#<glmnet:gaussian λ=0.1 dev=0.8321 nz=3/3>
> (predict m (list (cons "hp" '(100 200)) (cons "wt" '(2.5 3.5))))
'(24.262928395522646 17.32517427651279)
> (define logged (formula-fit (mpg . ~ . (log hp) + wt) mtcars #:lambda 0.1))
> (predict logged (list (cons "hp" '(100 200)) (cons "wt" '(2.5 3.5))))
'(24.008240583293016 16.76430275840009)
> (define by-cylinders (formula-fit (mpg . ~ . wt + (factor cyl)) mtcars #:lambda 0.1))
> (predict by-cylinders (list (cons "cyl" '(8 4)) (cons "wt" '(3.5 2.5))))
'(16.846901087575166 25.69733799740451)

procedure
(formula-model-levels m)
→ (listof (cons/c string? (listof string?)))
m : formula-model?

The levels of m’s factors, as R’s xlevels: for each variable of its terms that is a factor, in the order the variables first appear in the formula, a list of its name and the labels of its levels, the baseline first. A response column in an interaction is left out, as in R. A boolean variable has the levels "FALSE" and "TRUE", which R’s xlevels leaves out. predict codes new data with these levels.

Examples:

> (formula-model-levels
   (formula-fit (mpg . ~ . wt + (factor cyl)) mtcars #:lambda 0.1))
'(("(factor cyl)" "4" "6" "8"))
> (formula-model-levels
   (formula-fit (Sepal.Length . ~ . Species * Petal.Width + (> Sepal.Width 3))
                iris #:lambda 0.01))
'(("Species" "setosa" "versicolor" "virginica")
  ("(> Sepal.Width 3)" "FALSE" "TRUE"))
> (formula-model-levels
   (formula-fit (mpg . ~ . wt + hp) mtcars #:lambda 0.1))
'()

procedure
(formula-fit f
data
#:lambda lambda
[ #:family family
#:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters]) → formula-model?
  f : formula?
  data : (or/c table? named-data?)
  lambda : (>=/c 0)
   family : (or/c 'gaussian 'binomial 'multinomial 'poisson 'cox 'mgaussian)
= 'gaussian
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = the formula’s
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Fits f to data, a table or a dataframe, at a single λ, with the fit procedure of family: elnet-fit, logistic-fit, multinomial-fit, poisson-fit, cox-fit or mgaussian-fit, on the design matrix of f. The keywords are passed on to it. intercept? defaults to the formula’s intercept and must agree with a formula’s 1, 0 or - 1; the Cox family has no intercept, so it does not apply to it.

The response of f must suit family, which the contract on f checks: (surv time status) for the Cox family, one or more columns for the multi-response family, and one column otherwise. Its values must be ones the family models: 0 or 1 for the binomial family, class labels 0, 1, …, K−1 with K ≥ 2 and every class present for the multinomial family, non-negative for the Poisson family, and for the Cox family positive times and 0/1 statuses. An error names the column, and either the row of a value the family does not model or the missing class label. A binomial or multinomial response may instead hold strings, symbols or booleans, whose levels, sorted as a factor’s are, are its classes, as R’s glmnet makes a factor response’s: two for the binomial family, whose second is the class the model gives the probability of, and at least two for the multinomial family. An error that the family’s procedure raises names formula-fit.

Examples:

> (define fit (formula-fit (mpg . ~ . wt * hp) mtcars #:lambda 0.1))
> (coef fit)
'(("(Intercept)" . 37.528269700740594)
  ("wt" . -4.032185075172319)
  ("hp" . -0.03534015584099164)
  ("wt:hp" . 0.0013965478672480604))
> (coef (formula-fit (mpg . ~ . 0 + wt * hp) mtcars #:lambda 0.1))
'(("(Intercept)" . 0.0)
  ("wt" . 8.54890203027654)
  ("hp" . 0.1709322727567094)
  ("wt:hp" . -0.06445423956453895))
> (coef (formula-fit (mpg . ~ . hp + (I (expt hp 2))) mtcars #:lambda 0.1))
'(("(Intercept)" . 36.37284540325939)
  ("hp" . -0.15811445359642218)
  ("(I (expt hp 2))" . 0.00026508932547340944))
> (coef (formula-fit (mpg . ~ . wt + (factor cyl)) mtcars #:lambda 0.1))
'(("(Intercept)" . 33.87775166152442)
  ("wt" . -3.2721654656479635)
  ("(factor cyl)6" . -3.7451819901218832)
  ("(factor cyl)8" . -5.578271444181383))
> (formula-fit (am . ~ . wt + hp) mtcars #:family 'binomial #:lambda 0.05)
#<glmnet:binomial (~ am wt + hp) λ=0.05 dev=0.5891 nz=2/2>
> (map car (coef (formula-fit (~ Species all) iris #:family 'multinomial #:lambda 0.05)))
'("setosa" "versicolor" "virginica")
> (define car-model (formula-fit (~ mpg (+ wt hp)) cars #:lambda 0))
> (coef car-model)
'(("(Intercept)" . 37.227908544960556)
  ("wt" . -3.878178045360442)
  ("hp" . -0.03176968200102037))
> (predict car-model (pl:head cars 3))
'(23.57241704600396 22.583481644437047 25.27595505362944)
> (formula-fit (~ mpg 1) mtcars #:lambda 0.1)
formula-fit: the formula has no predictors, and glmnet needs
at least one
  formula: (~ mpg 1)
> (formula-fit (~ model wt) cars #:lambda 0.1)
formula-fit: the response column "model" is not numeric
  dtype: 'string

procedure
(formula-path f
data
[ #:family family
#:lambda lambda
#:nlambda nlambda
#:lambda-min-ratio lambda-min-ratio
#:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters])
→ formula-model?
  f : formula?
  data : (or/c table? named-data?)
   family : (or/c 'gaussian 'binomial 'multinomial 'poisson 'cox 'mgaussian)
= 'gaussian
  lambda : (or/c #f (and/c (listof (>=/c 0)) pair?)) = #f
  nlambda : exact-positive-integer? = 100
   lambda-min-ratio : (or/c #f (and/c real? (>=/c 0) (</c 1)))
= #f
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = the formula’s
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Fits the regularization path of f on data, with the path fitter of family, such as elnet-path, to which the keywords are passed. The response and the intercept are as for formula-fit, and an error that the path fitter raises names formula-path.

Examples:

> (define path
    (formula-path (~ mpg (^ (+ wt hp qsec) 2)) mtcars #:lambda '(1.0 0.5 0.1)))
> path
#<glmnet-path:gaussian (~ mpg (^ (+ wt hp qsec) 2))
  Df  %Dev Lambda
1  2 79.13    1.0
2  3 82.40    0.5
3  5 84.72    0.1>
> (coef path #:lambda 0.1)
'(("(Intercept)" . 26.53010769463421)
  ("wt" . -3.8107083219778004)
  ("hp" . 0.0)
  ("qsec" . 0.616278426076173)
  ("wt:hp" . 0.0023632916212049395)
  ("wt:qsec" . -0.023873512814479348)
  ("hp:qsec" . -0.001985660316630189))
> (formula-path (~ am (- all model)) cars #:family 'binomial #:nlambda 5)
#<glmnet-path:binomial (~ am (- all model))
  Df  %Dev  Lambda
1  0  0.00 0.39000
2  3 81.89 0.03900
3  4 97.37 0.00390
4  6 99.72 0.00039
5  6 99.97 0.00004>

procedure
(formula-cv f
data
[ #:family family
#:type-measure type-measure
#:nfolds nfolds
#:fold-ids fold-ids
#:grouped? grouped?
#:lambda lambda
#:nlambda nlambda
#:lambda-min-ratio lambda-min-ratio
#:alpha alpha
#:standardize? standardize?
#:intercept? intercept?
#:thresh thresh
#:max-iters max-iters])
→ formula-model?
  f : formula?
  data : (or/c table? named-data?)
   family : (or/c 'gaussian 'binomial 'multinomial 'poisson 'cox 'mgaussian)
= 'gaussian
   type-measure : (or/c #f 'mse 'deviance 'mae 'class 'auc 'C)
= #f
  nfolds : (and/c exact-integer? (>=/c 3)) = 10
  fold-ids : fold-ids/c = #f
  grouped? : boolean? = #t
   lambda : (or/c #f (and/c (listof (>=/c 0)) (property/c length (>=/c 2))))
= #f
  nlambda : exact-positive-integer? = 100
   lambda-min-ratio : (or/c #f (and/c real? (>=/c 0) (</c 1)))
= #f
  alpha : (real-in 0 1) = 1.0
  standardize? : boolean? = #t
  intercept? : boolean? = the formula’s
  thresh : (>/c 0) = 1e-7
  max-iters : exact-positive-integer? = 100000

Cross-validates the path of f on data with the cross-validation procedure of family, such as elnet-cv, to which the keywords are passed. type-measure must be one of the family’s measures (see Cross-validation), which the contract on it checks; #f, the default, is the family’s default. fold-ids needs one entry per row of data. The response and the intercept are as for formula-fit, and an error that the cross-validation procedure raises names formula-cv.

Examples:

> (define folds (for/list ([i (in-range 32)]) (modulo i 4)))
> (define cv-model (formula-cv (mpg . ~ . wt * hp) mtcars #:fold-ids folds))
> cv-model
#<glmnet-cv:gaussian (~ mpg wt * hp)
Measure: Mean-Squared Error
     Lambda Index Measure     SE Nonzero
min 0.00250    83    6.08 0.6064       3
1se 0.04477    52    6.61 0.6951       3>
> (coef cv-model)
'(("(Intercept)" . 44.18599782499345)
  ("wt" . -6.301381407673056)
  ("hp" . -0.08130232129662496)
  ("wt:hp" . 0.015743383605847892))
> (define iris-df (table->polars iris))
> (define flowers (formula-cv (~ Species all) iris-df #:family 'multinomial
                              #:fold-ids (for/list ([i (in-range 150)]) (modulo i 5))))
> (predict flowers (pl:head iris-df 3) #:type 'class #:lambda 'lambda-1se)
'("setosa" "setosa" "setosa")

2.17 Generic model interface🔗ℹ

Every result type implements one generic interface, gen:glmnet-model: the six single-λ results (elnet-result, logistic-result, multinomial-result, cox-result, poisson-result and mgaussian-result), glmnet-path, glmnet-cv and formula-model. predict, coef and deviance-ratio follow R’s predict, coef and dev.ratio for glmnet and cv.glmnet fits. See Predictions and coefficients.

The interface reads every model as a regularization path: a single-λ fit is a path with one λ. Where #:lambda names a λ that is not on the path, predict and coef follow R’s rule (its exact = FALSE, the default):

Between two fitted values λ_l > s > λ_r, the intercepts and coefficients are interpolated linearly in λ: β(s) = w β(λ_l) + (1 − w) β(λ_r), with w = (s − λ_r) / (λ_l − λ_r).
Above the largest fitted λ, or below the smallest, s is clamped to that end of the path.
A model with one λ, such as a single fit, gives that fit for every s.

A cross-validated model also names two λ values, 'lambda-min and 'lambda-1se, which #:lambda accepts in place of a number, as R’s s accepts "lambda.min" and "lambda.1se".

A model can also name its predictors, as a formula-model does. Then coef keys its coefficients by name, as R’s coef names its rows, and predict takes a table or a dataframe and reads the predictors from it by name, or, for a formula model, builds them from its columns, as its formula’s terms say.

predict, coef and glmnet-model-default-lambda need a model with at least one fitted λ. A glmnet-path built by hand can have none, and they reject such a model with a contract error that blames the caller.

The examples in this section use a single fit and a path of the Gaussian family:

> (require glmnet/data/polars
glmnet/datasets)
> (define X '((1.0 2.0 1.0) (2.0 1.0 4.0) (3.0 4.0 9.0)
(4.0 3.0 16.0) (5.0 6.0 25.0) (6.0 5.0 36.0)))
> (define y '(1.0 4.0 3.0 6.0 5.0 8.0))
> (define fit (lasso X y #:lambda 0.05))
> (define path (elnet-path X y #:lambda '(1.0 0.1 0.01)))

syntax
gen:glmnet-model

A generic interface for fitted models. It has six methods:

glmnet-model->path, which must be implemented;
glmnet-model-default-lambda, which defaults to the first λ of the model’s path;
glmnet-model-named-lambda, which defaults to naming no λ;
glmnet-model-predictor-names and glmnet-model-response-names, which default to naming no predictors and no responses;
deviance-ratio, which defaults to the first deviance ratio of the model’s path.

The defaults suit a single fit. glmnet-path and glmnet-cv implement the ones that differ for them, and formula-model implements all six. A new type, such as a path together with a chosen λ, implements the interface through the #:methods option of struct, and then works with predict and coef:

Examples:

> (require racket/generic)
> (struct chosen (path index)
    #:methods gen:glmnet-model
    [(define (glmnet-model->path m) (chosen-path m))
     (define (glmnet-model-default-lambda m)
       (vector-ref (glmnet-path-lambda (chosen-path m))
                   (chosen-index m)))
     (define (deviance-ratio m)
       (vector-ref (glmnet-path-dev-ratio (chosen-path m))
                   (chosen-index m)))])
> (define best (chosen path 1))
> (coef best)
'#(1.0000000000001843 1.6584349744677054 -0.6584349744677581 0.0)
> (deviance-ratio best)
0.9762711864406388

procedure
(glmnet-model? v) → boolean?
v : any/c

Returns #t if v implements gen:glmnet-model: every result type, glmnet-path, glmnet-cv and formula-model do.

Examples:

> (glmnet-model? fit)
#t
> (glmnet-model? path)
#t
> (glmnet-model? X)
#f

procedure
(glmnet-model->path model) → glmnet-path?
model : glmnet-model?

model as a glmnet-path. A single fit becomes a path with one λ, and a path is returned as it is.

Examples:

> (glmnet-model->path fit)
#<glmnet-path:gaussian
Df %Dev Lambda
1 2 99.41 0.05>
> (glmnet-path-coefficients (glmnet-model->path fit))
'#(#(1.8292174872340037 -0.8292174872340038 0.0))

procedure
(glmnet-model-default-lambda model)
→ (or/c (>=/c 0) (and/c (listof (>=/c 0)) pair?))
model : glmnet-model?

The #:lambda that predict and coef use when none is given: a single fit’s λ, or the list of a path’s fitted λ values, which is R’s default s = NULL. For a glmnet-cv it is glmnet-cv-lambda-1se, R’s default for cv.glmnet.

Examples:

> (glmnet-model-default-lambda fit)
0.05
> (glmnet-model-default-lambda path)
'(1.0 0.1 0.01)

procedure
(glmnet-model-named-lambda model name) → (or/c #f (>=/c 0))
model : glmnet-model?
name : (or/c 'lambda-min 'lambda-1se)

The λ that name stands for in model, or #f if the model does not name one. A glmnet-cv names its glmnet-cv-lambda-min and glmnet-cv-lambda-1se; single fits and paths name none, so predict and coef reject a name for them.

Examples:

> (glmnet-model-named-lambda path 'lambda-min)
#f
> (coef path #:lambda 'lambda-min)
coef: only a cross-validated model has a named lambda
lambda: 'lambda-min

procedure
(glmnet-model-predictor-names model)
→ (or/c #f (listof string?))
model : glmnet-model?

The names of model’s predictors, in the order of its coefficients, or #f if it does not name them. A formula-model names them, and so does a fit from named data (see Data arguments), which remembers them; a fit from unnamed data does not. When a model, such as a formula model, implements this method of gen:glmnet-model, coef keys its coefficients by these names and predict reads the columns with these names from a table or a dataframe, except that a formula model builds its predictors, such as the interaction "a:b" or the transform "(log a)", from its columns; the names a fit from named data remembers leave coef’s layout as it is. The names must be distinct, one per predictor of the model’s path; coef and predict raise an error for a model whose names are not.

Examples:

> (define named-model
    (formula-fit (~ y all)
                 (list (cons "y" y) (cons "a" (map car X))
                       (cons "b" (map cadr X)) (cons "c" (map caddr X)))
                 #:lambda 0.05))
> (glmnet-model-predictor-names named-model)
'("a" "b" "c")
> (glmnet-model-predictor-names car-fit)
'("wt" "hp")
> (glmnet-model-predictor-names fit)
#f

procedure
(glmnet-model-response-names model)
→ (or/c #f (listof string?))
model : glmnet-model?

The names of model’s response columns, or #f if it does not name them. For a formula-model, they are the columns of its formula’s response: for the Cox family the time and status columns. For a multi-response formula model, coef keys the coefficients of each response by its name, and raises an error for a model that does not name each response once. A multi-response fit from named data remembers its responses’ names, which leave coef’s layout as it is.

Examples:

> (glmnet-model-response-names named-model)
'("y")
> (glmnet-model-response-names path)
#f

procedure
(glmnet-model-class-labels model) → (or/c #f (listof string?))
model : glmnet-model?

The labels of a binomial or multinomial model’s classes, in the order of the class indices, or #f if it does not name them. A fit of a response of strings, symbols or booleans, a formula model’s included, names them (see Data arguments), and predict with #:type 'class returns them; a fit of class numbers does not.

Examples:

> (glmnet-model-class-labels flowers)
'("setosa" "versicolor" "virginica")
> (glmnet-model-class-labels (multinomial-fit X '(0 1 2 0 1 2) #:lambda 0.05))
#f

procedure
(deviance-ratio model) → (or/c real? (vectorof real?))
model : glmnet-model?

The fraction of null deviance explained, which is R² for the Gaussian families: a real for a single fit, and for a path a vector with one entry per fitted λ, R’s dev.ratio. It is not interpolated.

Examples:

> (deviance-ratio fit)
0.9940677966101694
> (deviance-ratio path)
'#(0.6106537530266343 0.9762711864406388 0.9997591646825783)

procedure
(predict model X [#:type type #:lambda lambda]) → list?
  model : glmnet-model?
  X : data/c
  type : (or/c 'link 'response 'class) = 'link
   lambda :
(or/c (>=/c 0) (and/c (listof (>=/c 0)) pair?)
      'lambda-min 'lambda-1se)
= (glmnet-model-default-lambda model)

Predictions for each row of X, as R’s predict(fit, newx, s, type). X needs one column per coefficient, in the order of the coefficients. For a model that names its predictors (see glmnet-model-predictor-names), X is instead a table or a dataframe with a column of each of those names, in any order; its other columns are ignored, and a missing one is an error that names it. For a formula-model, X needs the columns that the formula’s terms read, from which predict builds the design matrix as formula-design-matrix does, transforms included; an error names the missing ones. A fit from named data (see Data arguments) reads named X, a table or a dataframe, by its predictors’ names, and unnamed X by position. Any other model reads X by position, and so does not take named data. type chooses what is predicted:

Family	'link	'response	'class
Gaussian, multi-response	η = β₀ + xβ	η	---
Binomial	log-odds η	P(y = 1)	1 if η > 0, else 0
Multinomial	η_k, one per class	softmax of the η_k	the class with the largest η_k
Cox	xβ	exp(xβ)	---
Poisson	log μ = η	μ = exp(η)	---

'class is an error for the families without classes. A class is its label, 0, 1, …, except for a formula-model or a fit whose response holds strings, symbols or booleans, whose classes are the labels of its levels, such as "setosa" (see formula-fit and Data arguments). For one λ, the result has one entry per row of X: a real, a class, or, for the multinomial and multi-response families, a list with one entry per class or response. When lambda is a list, the result is a list of those, one per element of lambda, in the same order. 'lambda-min and 'lambda-1se stand for the λ values a glmnet-cv chose (see glmnet-model-named-lambda).

Examples:

> (predict fit '((7.0 6.0 49.0) (0.0 0.0 0.0)))
'(8.829217487234002 0.9999999999999996)
> (predict path '((7.0 6.0 49.0)) #:lambda 0.5)
'(7.72162380661891)
> (predict path '((7.0 6.0 49.0)) #:lambda '(2.0 0.5 0.01))
'((6.550609846808079) (7.72162380661891) (8.972181135456438))
> (define clf (logistic-fit X '(0 0 0 1 1 1) #:lambda 0.05))
> (predict clf '((2.0 3.0 4.0) (5.0 4.0 25.0)))
'(-2.7629680455517835 2.7629680455517853)
> (predict clf '((2.0 3.0 4.0) (5.0 4.0 25.0)) #:type 'response)
'(0.05935842823867659 0.9406415717613236)
> (predict clf '((2.0 3.0 4.0) (5.0 4.0 25.0)) #:type 'class)
'(0 1)
> (predict fit X #:type 'class)
predict: type 'class is only for the binomial and
multinomial families
  family: 'gaussian
> (define new-table
    (list (cons "c" '(49.0)) (cons "b" '(6.0)) (cons "a" '(7.0))))
> (predict named-model new-table)
'(8.829217487234002)
> (predict named-model (table->polars new-table))
'(8.829217487234002)
> (predict named-model (cdr new-table))
predict: the table has no column with this name
  column: "c"
  columns of the table: '("b" "a")

procedure
(coef model [#:lambda lambda]) → (or/c vector? list?)
  model : glmnet-model?
   lambda :
(or/c (>=/c 0) (and/c (listof (>=/c 0)) pair?)
      'lambda-min 'lambda-1se)
= (glmnet-model-default-lambda model)

The intercept and coefficients at lambda, as R’s coef(fit, s): a vector holding the intercept, then one coefficient per predictor. Cox models have no intercept, so their vector holds only the coefficients. For the multinomial and multi-response families the result is a vector of such vectors, one per class or response. When lambda is a list, the result is a list with one entry per element of lambda. As for predict, lambda can name a λ that a glmnet-cv chose.

For a model that names its predictors, each vector is an association list instead, keyed as R’s coef names its rows: "(Intercept)" (not for Cox), then the predictor names. For the multinomial family, the association lists are in turn keyed by class, as predict labels the classes, and for the multi-response family by response name (see glmnet-model-response-names; "y1", "y2", … when the model names no responses), as R names the elements of its lists.

Examples:

> (coef fit)
'#(0.9999999999999996 1.8292174872340037 -0.8292174872340038 0.0)
> (coef path #:lambda 0.1)
'#(1.0000000000001843 1.6584349744677054 -0.6584349744677581 0.0)
> (coef path #:lambda 0.4)
'#(1.483130051064096 1.3009194921982872 -0.43895664964517206 0.0)
> (coef path #:lambda 5.0)
'#(2.449390153191919 0.5858885276594514 0.0 0.0)
> (coef named-model)
'(("(Intercept)" . 0.9999999999999996)
  ("a" . 1.8292174872340037)
  ("b" . -0.8292174872340038)
  ("c" . 0.0))
> (coef (glmnet-path 'gaussian (vector) (vector) (vector)
                     (vector) (vector) 0))
coef: contract violation;
the model has at least one fitted λ
      model: #<glmnet-path:gaussian
Df %Dev Lambda>
  in: (->i
       ((model glmnet-model?))
       (#:lambda
        (s
         (or/c
          (or/c
           (>=/c 0)
           (non-empty-listof (>=/c 0)))
          (or/c 'lambda-min 'lambda-1se))))
       #:pre/name
       (model)
       "the model has at least one fitted λ"
       (fitted? model)
       (result (or/c vector? (listof any/c))))
  contract from: <pkgs>/glmnet/core/model.rkt
  blaming: program
   (assuming the contract is correct)
  at: <pkgs>/glmnet/core/model.rkt:81:3

procedure
(in-path model) → sequence?
model : glmnet-model?

A sequence that walks model’s regularization path, with two values per element: each fitted λ, in the path’s order, and the coefficients at that λ as coef gives them, keyed by name for a model that names its predictors. A single fit is a path with one λ, and a glmnet-cv walks its path of all the data. Nothing is interpolated: each element holds the path’s own fit at its λ.

Examples:

> (for ([(λ β) (in-path path)])
    (printf "~a: ~a\n" λ β))
1.0: #(2.449390153191919 0.5858885276594514 0.0 0.0)
0.1: #(1.0000000000001843 1.6584349744677054 -0.6584349744677581 0.0)
0.01: #(1.0089698059122343 1.9597271819899955 -0.9658434974467867 0.0008200416386725593)
> (for/list ([(λ β) (in-path (formula-path (~ mpg (+ wt hp)) mtcars #:nlambda 4))])
    β)
'((("(Intercept)" . 20.090624999999996) ("wt" . 0.0) ("hp" . 0.0))
  (("(Intercept)" . 36.43365390533786)
   ("wt" . -3.7286031193229756)
   ("hp" . -0.029635657569295454))
  (("(Intercept)" . 37.19156099616917)
   ("wt" . -3.871517446859316)
   ("hp" . -0.0316679777776637))
  (("(Intercept)" . 37.22625501504155)
   ("wt" . -3.8778871518235714)
   ("hp" . -0.03176478960945665)))

2.17.1 Printing🔗ℹ

A single fit prints on one line with its family, its λ (to four significant digits), its deviance ratio (to four decimal places) and the number of nonzero coefficients out of the number of predictors, counting a predictor once when it is nonzero for any class or response.

A path prints R’s print.glmnet table line for line, without the Call: line R prints above it. Each fitted λ has a row, numbered from 1, with Df, the deviance ratio as a percentage rounded to two places (%Dev), and λ to four significant digits (Lambda). As in R, %Dev and Lambda are then rounded to about five significant digits of the column’s largest value, so a λ far below the first can show as 0, and each column is written with one number of decimals throughout, or in scientific notation when that is narrower.

A glmnet-cv prints as R’s print.cv.glmnet, without its Call: line and blank lines, under a #<glmnet-cv:family header. A formula-model prints as the result it holds, with its formula after the family.

Printing does not change equal?, which compares results field by field.

Examples:

> (list fit clf)
'(#<glmnet:gaussian λ=0.05 dev=0.9941 nz=2/3>
  #<glmnet:binomial λ=0.05 dev=0.8046 nz=1/3>)
> (define Xm '((1.0 1.0) (2.0 1.0) (5.0 1.0) (6.0 1.0) (3.0 5.0) (4.0 6.0)))
> (multinomial-fit Xm '(0 0 1 1 2 2) #:lambda 0.05)
#<glmnet:multinomial λ=0.05 dev=0.9150 nz=2/2>
> (multinomial-path Xm '(0 0 1 1 2 2) #:nlambda 4)
#<glmnet-path:multinomial
  Df  %Dev  Lambda
1  0  0.00 0.46710
2  2 96.30 0.02168
3  2 99.82 0.00101
4  2 99.99 0.00005>
> cv
#<glmnet-cv:gaussian
Measure: Mean-Squared Error
     Lambda Index Measure      SE Nonzero
min 0.05424    38  0.3984 0.05967       6
1se 0.16564    26  0.4468 0.06523       3>
> named-model
#<glmnet:gaussian (~ y all) λ=0.05 dev=0.9941 nz=2/3>
> (equal? fit (lasso X y #:lambda 0.05))
#t

2.18 Native library🔗ℹ

These call straight into libglmnetcompat. Loading glmnet checks both and raises exn:fail if either is wrong. See The native library.

procedure
(glmnet-default-real-bytes) → exact-positive-integer?

The width in bytes of the Fortran default real in the loaded library. It is 8 for a correctly built library, which the numeric API requires.

Example:

> (glmnet-default-real-bytes)
8

procedure
(glmnet-capi-abi-version) → exact-positive-integer?

The version of the C entry points the library exports. It changes whenever an entry point is added or changed incompatibly.

Example:

> (glmnet-capi-abi-version)
3

2.19 Plots🔗ℹ

(require glmnet/plot)

package: glmnet

glmnet/plot draws a glmnet-path and a glmnet-cv, or a formula-model that holds one, as R’s plot draws a glmnet and a cv.glmnet fit. The guide’s Plots chapter shows every plot and how to read it. glmnet does not re-export these bindings, so that (require glmnet) does not load the plot library. Each plot is a pict?, drawn with plot/no-gui, whose parameters apply to it, and each plot procedure has a companion that returns the plot’s renderers, without the axes, to combine with other plot-lib renderers.

The examples in this section plot the lasso path of the fixture of Gaussian models, a multinomial path of three separable classes, the cross-validated fit cv of Cross-validation, and the formula model cv-model of formula-cv:

> (require glmnet/datasets
           glmnet/plot)
> (define X '((1.0 2.0 1.0) (2.0 1.0 4.0) (3.0 4.0 9.0)
              (4.0 3.0 16.0) (5.0 6.0 25.0) (6.0 5.0 36.0)))
> (define y '(1.0 4.0 3.0 6.0 5.0 8.0))
> (define path (elnet-path X y))
> (define X3 '((1.0 1.0) (2.0 1.0) (1.0 2.0) (2.0 2.0)
               (5.0 1.0) (6.0 1.0) (5.0 2.0) (6.0 2.0)
               (3.0 5.0) (4.0 5.0) (3.0 6.0) (4.0 6.0)))
> (define mpath (multinomial-path X3 '(0 0 0 0 1 1 1 1 2 2 2 2)))

procedure
(plot-coefficient-path model
[ #:xvar xvar
#:sign-lambda sign-lambda
#:label label
#:type-coef type-coef
#:width width
#:height height
#:title title
#:out-file out-file]) → pict?
  model : (or/c glmnet-path? glmnet-cv? formula-model?)
  xvar : (or/c 'lambda 'norm 'dev) = 'lambda
  sign-lambda : (or/c -1 1) = -1
   label : (or/c boolean? design-matrix? (listof (or/c string? symbol?)))
= #f
  type-coef : (or/c 'coef '2norm) = 'coef
  width : exact-positive-integer? = (plot-width)
  height : exact-positive-integer? = (plot-height)
  title : (or/c #f string?) = (plot-title)
  out-file : (or/c #f image-path/c) = #f

Plots the coefficients of model’s path against xvar, as R’s plot.glmnet does (see Coefficient paths). For a glmnet-cv, it plots the path fitted to all the data. For a formula-model, it plots the model’s fit, which must be a path or a glmnet-cv.

xvar is 'lambda for sign-lambda times log λ, 'norm for the L1 norm of the coefficients, or 'dev for the fraction of deviance explained.
label labels each curve at the end of the path: #f for no labels, #t for the predictor’s name if the model names its predictors, as a formula-model and a fit from named data (see Data arguments) do, and otherwise its position counting from 1, or the names of the predictors, as a list or as the column names of a design matrix. A design matrix without column names gives positions.
type-coef applies to the multinomial and multi-response families: 'coef stacks one plot per class or response, '2norm draws one plot of the 2-norms across them.
width and height are the size of each plot in pixels, and title is its title.
out-file, when given, names a file to which the plot is also written, in the format its extension names (see image-path/c).

An error is raised if every coefficient is zero at every λ, as there is then nothing to plot. A λ of 0 has no position on a log λ axis and is left out: the curves, and their labels, end at the smallest positive λ. If every λ of the path is 0, an error is raised for a log λ axis, as R’s plot stops too; the path can still be plotted against the L1 norm or the deviance ratio.

Examples:

> (plot-coefficient-path path #:xvar 'norm #:label '("x1" "x2" "x3")
                         #:width 400 #:height 300 #:title "Lasso path")
> (plot-coefficient-path (elnet-path mtcars "mpg" #:predictors '("wt" "hp" "qsec"))
                         #:label #t #:width 400 #:height 300)
> (plot-coefficient-path (elnet-path X y #:lambda '(10.0 5.0)))
plot-coefficient-path: every coefficient is zero at every λ,
so there is nothing to plot
  λ values: 2
> (plot-coefficient-path (elnet-path X y #:lambda '(0.0)))
plot-coefficient-path: every λ of the path is 0, which has
no place on a log λ axis
  λ values: '(0.0)
  xvar: 'lambda

procedure
(coefficient-path-renderers model
[ #:xvar xvar
#:sign-lambda sign-lambda
#:label label
#:type-coef type-coef
#:response response])
→ (listof renderer2d?)
  model : (or/c glmnet-path? glmnet-cv? formula-model?)
  xvar : (or/c 'lambda 'norm 'dev) = 'lambda
  sign-lambda : (or/c -1 1) = -1
   label : (or/c boolean? design-matrix? (listof (or/c string? symbol?)))
= #f
  type-coef : (or/c 'coef '2norm) = 'coef
  response : exact-nonnegative-integer? = 0

The renderers of one plot of plot-coefficient-path: a line for each predictor that is nonzero at some λ, and a label for each when label asks for them. For the multinomial and multi-response families with type-coef 'coef, response chooses the class or response, counting from 0; for the others it must be 0. The list is empty when every coefficient is zero.

The axes are not included. Labels start at the end of the path, where plot-lib cuts them off unless the x axis is widened.

Examples:

> (length (coefficient-path-renderers path))
3
> (length (coefficient-path-renderers path #:label #t))
6
> (length (coefficient-path-renderers mpath #:response 2))
1

procedure
(plot-cv cv
[ #:sign-lambda sign-lambda
#:width width
#:height height
#:title title
#:out-file out-file]) → pict?
  cv : (or/c glmnet-cv? formula-model?)
  sign-lambda : (or/c -1 1) = -1
  width : exact-positive-integer? = (plot-width)
  height : exact-positive-integer? = (plot-height)
  title : (or/c #f string?) = (plot-title)
  out-file : (or/c #f image-path/c) = #f

Plots the cross-validation curve of cv against sign-lambda times log λ, as R’s plot.cv.glmnet does (see Cross-validation curves), with the number of nonzero coefficients along the top. A formula-model must hold a glmnet-cv, from formula-cv. width, height, title and out-file are as for plot-coefficient-path. As there, a λ of 0 is left out, and an error is raised if every λ is 0.

Example:

> (plot-cv cv #:sign-lambda 1 #:width 400 #:height 300)

procedure
(cv-renderers cv [#:sign-lambda sign-lambda])
→ (listof renderer2d?)
cv : (or/c glmnet-cv? formula-model?)
sign-lambda : (or/c -1 1) = -1

The renderers of plot-cv: the error bars, the points, and a vertical line at each of glmnet-cv-lambda-min and glmnet-cv-lambda-1se. The axes are not included.

Examples:

> (length (cv-renderers cv))
4
> (length (cv-renderers cv-model))
4

value
image-path/c : flat-contract?

The contract on the #:out-file argument of plot-coefficient-path and plot-cv: a path-string? ending in ".png", ".pdf", ".svg" or ".eps", in any case. The extension names the format the plot is written in. As for path-get-extension, a name such as ".png" has no extension.

Examples:

> (contract-first-order-passes? image-path/c "lasso.PNG")
#t
> (contract-first-order-passes? image-path/c "lasso.jpg")
#f
> (plot-cv cv #:out-file "cv.jpg")
plot-cv: contract violation
  expected: (or/c #f image-path/c)
  given: "cv.jpg"
  in: the #:out-file argument of
      (->*
       ((or/c glmnet-cv? formula-model?))
       (#:height
        exact-positive-integer?
        #:out-file
        (or/c #f image-path/c)
        #:sign-lambda
        (or/c -1 1)
        #:title
        (or/c #f string?)
        #:width
        exact-positive-integer?)
       pict?)
  contract from: <pkgs>/glmnet/plot.rkt
  blaming: program
   (assuming the contract is correct)
  at: <pkgs>/glmnet/plot.rkt:82:3

2.1	Common arguments
2.2	Input data
2.3	Nested lists and vectors
2.4	CSV files
2.5	Matrices from math/ matrix
2.6	Polars dataframes
2.7	Example datasets
2.8	Gaussian models
2.9	Binomial models
2.10	Multinomial models
2.11	Cox models
2.12	Poisson models
2.13	Multi-response Gaussian models
2.14	Regularization paths
2.15	Cross-validation
2.16	Formulas
2.17	Generic model interface
2.18	Native library
2.19	Plots
